Al Summan Metals, based in Dubai, UAE, has established a strong reputation as a manufacturer and supplier of high-quality Copper Bars and Rods. They are recognized for their precision, durability, and compliance with international standards, offering copper products engineered for reliable performance across electrical, industrial, and mechanical applications. Their Copper Bars and Rods are valued for their outstanding conductivity, corrosion resistance, and machinability, guaranteeing long-lasting efficiency and performance. With advanced manufacturing methods, stringent quality control, and timely delivery, Al Summan Metals provides copper solutions that satisfy the demanding requirements of industries in the UAE and worldwide, delivering reliability and outstanding value.
These Copper Bars and Rods are crafted from high-purity copper, typically 99.9% or above, which ensures exceptional electrical and thermal conductivity. They feature tensile strength ranging from 210–250 MPa and yield strength of about 70–120 MPa, along with elongation rates of 30–50%. Their impressive corrosion resistance, solid ductility, and straightforward machinability make them an excellent option. By pairing high conductivity with mechanical strength, Copper Bars and Rods are ideal for industrial uses that demand both electrical efficiency and structural integrity.
| Specifications | ASTM B187, ASTM B301 / ASME SB187, SB301 |
| Range | 3.17 MM TO 350 MM DIA |
| Form | Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc. |
| Material | Copper |
| ETP GRADE | |
|---|---|
| Copper Hex Bar | ø 8 mm to 110 mm |
| Copper Round | ø 7 mm to 120 mm |
| Copper Square Bar | 10*10 mm to 90*90 mm |
| Electrical Conductivity: – (% IACS) | 98.5% min |
| Standards | BS EN 13601:2013, IS: 191, 1897 & 613 |
| Specifications | Cu : 99.90%, 02<400ppm |
| Copper Round Rod C101 | |
|---|---|
| 6.3mm (1/4″) | 38.1mm (1 1/2″) |
| 9.5mm (3/8″) | 30mm |
| 12.7mm (1/2″) | 25.4mm (1″) |
| 12mm | 25mm |
| 10mm | 20mm |
| 16mm | 19mm (3/4 |
| Diameter in mm | Weight in Kg/m |
|---|---|
| 8 | 0,447 |
| 6 | 0,252 |
| 9,5 | 0,631 |
| 12 | 1,007 |
| 11 | 0,846 |
| 60 | 25,164 |
| 12,5 | 1,092 |
| 14 | 1,370 |
| 42 | 12,330 |
| 13 | 1,181 |
| 70 | 34,251 |
| 16 | 1,789 |
| 80 | 44,736 |
| 38 | 10,094 |
| 35 | 8,563 |
| 50 | 17,475 |
| 40 | 11,184 |
| 20 | 2,796 |
| 19 | 2,523 |
| 22 | 3,383 |
| 28 | 5,480 |
| 30 | 6,291 |
| 25 | 4,369 |
| 32 | 7,158 |
| 45 | 14,155 |
| Molecular Weight | 63.55 |
|---|---|
| Boiling Point | 2567 °C |
| Melting Point | 1083.4 °C |
| Density | 8.96 g/cm3 |
| Electrical Resistivity | 1.678 microhm-cm @ 20 °C |
| Appearance | Reddish Metal |
| Young’s Modulus | 110–128 GPa |
| Solubility in H2O | N/A |
| Heat of Fusion | 3.11 Cal/gm mole |
| Electronegativity | 1.9 Paulings |
| Poisson’s Ratio | 0.34 |
| Heat of Vaporization | 72.8 K-cal/gm atom at 2567 °C |
| Tensile Strength | N/A |
| Specific Heat | 0.092 Cal/g/K @ 25 °C |
| Thermal Expansion | (25 °C) 16.5 µm·m-1·K-1 |
| Thermal Conductivity | 4.01 W/cm/K @ 298.2 K |
| Vickers Hardness | 369 MPa |
Yes, Copper Bars and Rods can be prone to galvanic corrosion when they come into contact with dissimilar metals, especially where moisture or electrolytes are present. Adequate insulation helps prevent this.
Yes, Copper Bars and Rods can be completely recycled. The material keeps its properties even after recycling, which makes it an environmentally friendly option for sustainable industrial uses and lowering environmental impact.
Yes, Copper Bars and Rods are suitable for natural gas applications. They provide outstanding corrosion resistance and conductivity, which makes them a good fit for gas systems, as long as they are maintained properly.
Copper Bars and Rods are widely used across numerous sectors, such as electrical, electronics, construction, and industry. They work perfectly for making busbars, electrical connectors, terminals, grounding systems, and switchgear components. On top of that, they serve applications in plumbing, heat exchangers, and mechanical parts requiring outstanding corrosion resistance and thermal conductivity. Thanks to their high ductility and conductivity, they’re also well suited for wiring, renewable energy systems, and parts used in industrial machinery. Combining reliability, durability, and exceptional conductivity, Copper Bars and Rods stand as truly indispensable materials within both the industrial and electrical engineering fields.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
