Al Summan Metals distinguishes itself as a premier manufacturer and supplier based in Dubai, UAE, specializing in high-quality **Titanium Flat Bars** designed for demanding industrial applications. Well-known for their precision engineering and steadfast quality, Al Summan Metals creates Titanium Flat Bars that offer remarkable strength, corrosion resistance, and enduring durability. Made with careful attention to dimensional accuracy and smooth surface finishes, these bars are ideal for both structural and functional applications. Serving industries such as aerospace, marine, chemical processing, and healthcare, Al Summan Metals ensures reliable products that satisfy rigorous performance standards and support efficient long-term operation.
When it comes to **Titanium Flat Bars**, they are typically manufactured from commercially pure titanium or titanium alloys, such as Grades 1, 2, 5, or 12, depending on the requirements of the application. They provide an excellent combination of mechanical properties, featuring high tensile strength (spanning from 240 to 900 MPa) and yield strength, together with good ductility and elongation. These flat bars perform exceptionally at resisting corrosion in both oxidizing and reducing conditions, and they deliver superb weldability and formability, which makes them versatile for a wide range of industrial applications.
| Standard | ASTM B348, ASME B348, ASTM B863, ASTM F67, ASTM F136 |
| Application | Industrial and Medical |
| Shape | Flat |
| size | Dia 5.0~350 X ≤ 6000 |
| Grade | Gr1, Gr2, Gr3, Gr4, Gr5, Gr7,Gr23,Ti15333 |
| Density | 4.53 g/cm3 |
| Techniques | Forged,Rolled, Extrusion |
| Surface | Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline |
| Technique | TC4 Titanium Alloy Hot Rolled, Cold Rolled, Cold Drawn, Forged |
Hardness, Brinell | 120 | 120 | annealed |
Hardness, Knoop | 132 | 132 | Estimated from Brinell. |
Hardness, Rockwell B | 70 | 70 | annealed |
Hardness, Vickers | 122 | 122 | Estimated from Brinell |
Tensile Strength, Ultimate | 240 MPa | 34800 psi | – |
Tensile Strength, Yield | 170 – 310 MPa | 24700 – 45000 psi | – |
Elongation at Break | 24 % | 24 % | – |
Reduction of Area | 35 % | 35 % | – |
Modulus of Elasticity | 105 GPa | 15200 ksi | In Tension |
Compressive Modulus | 110 GPa | 16000 ksi | – |
Poisson’s Ratio | 0.37 | 0.37 | – |
Charpy Impact | 310 J | 229 ft-lb | V-notch |
Shear Modulus | 45 GPa | 6530 ksi | – |
|
Physical Properties |
Metric |
English |
|
Density |
4.51 g/cc |
0.163 lb/in³ |
| Physical Properties | Metric | English |
|---|---|---|
| Density | 4.51 g/cc | 0.163 lb/in³ |
|
STANDARD |
WERKSTOFF NR. |
UNS |
|
Titanium |
3.7035 / 3.7165 / 3.7235 |
R50400 / R56400 / R52400 |
Titanium Flat Bars are frequently employed across the aerospace, medical, and chemical sectors for parts such as frames, brackets, and heat exchangers, thanks to their durability and resistance to corrosion.
Yes, Titanium Flat Bars are weldable, though they demand accurate heat management to prevent contamination and preserve the material's strength and resistance to corrosion.
Yes, we supply bars and rods in both standard and custom sizes and finishes to suit your particular project needs. For further information, email us at sales@alsummanmetals.ae
Titanium Flat Bars are in high demand across industries that require lightweight, strong, and corrosion-resistant materials. They’re commonly seen in chemical processing equipment, heat exchangers, marine hardware, and desalination plants, owing to their capacity to endure seawater and aggressive chemicals. Within the aerospace and automotive sectors, they serve in structural components and high-performance assemblies. Furthermore, in medical and surgical applications, Titanium Flat Bars act as raw materials for implants, instruments, and prosthetic parts, delivering durability, biocompatibility, and enduring reliability.
Our offerings include products supplied with mill test certificates as well as third-party test certificates, guaranteeing the highest standards of quality and compliance.
