Al Summan Metals is a dependable manufacturer and supplier of Monel Bars and Rods, based in Dubai, UAE. They focus on delivering premium nickel-copper alloy solutions for a wide range of industrial requirements. The company takes pride in its precision manufacturing, strict quality control, and compliance with international standards, guaranteeing that their products feature outstanding strength, durability, and corrosion resistance. Monel Bars and Rods are well-known for their remarkable mechanical properties, toughness, and capacity to withstand severe and corrosive conditions. With a dedication to on-time delivery, competitive pricing, and excellent customer support, Al Summan Metals serves industries including marine, chemical, aerospace, power generation, and heavy engineering, providing dependable and high-performance Monel alloy products.
Monel Bars and Rods consist primarily of nickel and copper, along with minor quantities of iron and manganese, which give them their notable corrosion resistance, strength, and toughness. These bars demonstrate high tensile strength, good ductility, and outstanding resistance to pitting, crevice corrosion, and stress-corrosion cracking. Monel retains its dimensional stability and mechanical integrity even under high temperatures and harsh chemical environments. Its well-balanced composition ensures lasting durability, remarkable mechanical performance, and reliable operation in demanding industrial settings, making it well-suited for applications where both corrosion resistance and high strength are crucial.
Monel Round Bar Specification :ASTM B164 / A479, ASME SB164 / A479
Dimension Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 14mm-300mm
Thickness : 50 mm to 6000 mm in Length
Length : 1 To 6 Meters, Custom Cut Length
Form : Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.
| Grade | Ni | Fe | C | Mn | Si | Cu | Al | Ti | S |
|---|---|---|---|---|---|---|---|---|---|
| 400 | 63.0- 70.00 max | 2.50 max | 0.3 max | 2.00 max | 0.50 max | Remainder | – | – | 0.024 max |
| K500 | 63.0 min | 05 – 2 | 0.25 max | 1.5 max | 0.5 max | 27.0 – 33.0 | 2.3 – 3.15 | 0.35 – 0.85 | 0.010 max |
| Grade | Tensile (ksi) | .2% Yield (ksi) | Elongation % | Hardness (HRb) |
|---|---|---|---|---|
| 400 | 75 to 90 | 25 to 50 | 60 to 35 | 60 to 80 |
| K500 | Psi – 1,60,000 , MPa – 1100 | Psi – 1,15,000 , MPa – 790 | 20 % | – |
| STANDARD | UNS | WNR. | JIS | EN |
|---|---|---|---|---|
| Monel 400 | N04400 | 2.4360 | NW 4400 | NiCu30Fe |
| Monel K500 | N05500 | 2.4375 | – | – |
Yes, Monel alloy bars offer high resistance to corrosion, especially against seawater, acids, and alkalis. This outstanding resistance makes them well-suited for demanding environments and uses that call for long-lasting performance.
Yes, Monel rods can be tailored in both size and length to satisfy particular application needs. They come in a range of diameters and lengths, providing flexibility for various industries.
Monel alloy bars and rods deliver outstanding performance in high-temperature settings, retaining their strength and resistance to oxidation. They are well suited for use in extreme heat, including applications in chemical processing and marine industries.
Monel Bars and Rods are widely applied in industries that require materials able to endure corrosive, high-stress, and marine conditions. They are frequently used in marine settings for shafts, propellers, pumps, and seawater-handling equipment. Within chemical processing, Monel bars serve in heat exchangers, piping systems, and reaction vessels. The alloy also suits aerospace, oil and gas, and high-performance mechanical components exposed to severe operating conditions. Its distinctive combination of toughness, corrosion resistance, and mechanical strength makes Monel an outstanding option for demanding applications.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest levels of quality and compliance.
