Al Summan Metals, headquartered in Dubai, UAE, distinguishes itself as a leading manufacturer and supplier of premium Monel Rectangular Bars. Placing a strong emphasis on precision, quality, and dependability, Al Summan Metals supplies nickel-copper alloy products that comply with international standards, ideal for demanding industrial uses. Their Monel Rectangular Bars are engineered to provide exceptional corrosion resistance, mechanical strength, and durability, making them well-suited for harsh and high-stress conditions. Through advanced manufacturing methods, stringent quality control, and timely delivery, Al Summan Metals ensures that every product delivers superior performance, enduring reliability, and excellent value, cementing its standing as a trusted supplier of specialty alloy solutions across UAE and beyond.
Monel Rectangular Bars are nickel-copper alloys that generally consist of about 63% nickel, 28–34% copper, together with minor quantities of iron, manganese, and silicon. Regarding their mechanical characteristics, these bars offer a tensile strength between 550 and 700 MPa, a yield strength spanning 240 to 400 MPa, and an elongation of 30 to 50%. This blend yields exceptional toughness, ductility, and corrosion resistance. Their distinctive makeup delivers outstanding defense against pitting, oxidation, and stress corrosion cracking across both acidic and alkaline settings, rendering them well-suited for industrial, marine, and chemical uses that require dependable performance under severe conditions.
| Monel Rectangular Bar Standard | ASTM B164, ASTM B865, AMS 5513, AMS 5511, AMS 5647 |
|---|---|
| Monel Rectangular Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Alloy Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Monel Rectangular Size | 33 x 30mm to 295 x 1066mm |
| JIS NW Rectangular-Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Rolled Monel Rectangular Bars Condition | Hardened & tempered, annealed |
| Type Cold Rolled Retangular Bar Technique | Alloy Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Monel Alloy Rod Processing | Bar cutting to 650mm |
| Element | Max | Min |
| Ni | – | 63.0 |
| Fe | 1.0 – 2.5 | – |
| C | 0.3 | – |
| Mn | 2.0 | – |
| Si | 0.5 | – |
| Cu | 28.0 – 34.0 | – |
| Al | 0.50 | – |
| S | 0.02 | – |
| Element | Monel |
| Density | 8.8 g/cm3 |
| Melting Point | 1350 °C (2460 °F) |
| Tensile Strength | Psi – 80,000 , MPa – 550 |
| Yield Strength (0.2%Offset) | Psi – 35,000 , MPa – 240 |
| Elongation | 40 % |
Yes, we supply bars and rods in both standard and custom sizes and finishes to suit your particular project needs. For further information, email us at sales@alsummanmetals.ae
Monel Rectangular Bars find application in the oil and gas industry for producing components like piping, valves, and heat exchangers, where withstanding corrosion and high pressure is essential.
Monel Rectangular Bars retain outstanding strength and stability under high-temperature conditions, which makes them well-suited for heat exchangers, reactors, and other high-heat industrial uses.
Monel Rectangular Bars are widely applied in chemical processing, marine engineering, desalination plants, and the aerospace sector, owing to their outstanding corrosion resistance and mechanical strength. They are ideal for building pumps, valves, heat exchangers, piping systems, and structural components that come into contact with seawater or harsh chemicals. Furthermore, these bars serve in fittings, shafts, and industrial equipment demanding high durability, wear resistance, and long-term reliability. The combination of toughness, corrosion resistance, and performance makes Monel Rectangular Bars a preferred option for critical and high-demand applications.
Our products are supplied with mill test certificates as well as third-party test certificates, guaranteeing top-tier quality and compliance standards.
