Al Summan Metals is a well-regarded manufacturer and supplier of premium Stainless Steel Flat Bars, proudly located in Dubai, UAE. With a strong emphasis on precision engineering and superior-quality materials, this company supplies durable, corrosion-resistant stainless steel products that comply with international standards. Al Summan Metals serves a wide range of industries, including construction, automotive, marine, and manufacturing, offering tailored sizes and finishes to suit numerous applications. Backed by advanced technology, strict quality control, and a skilled workforce, Al Summan Metals reliably provides dependable stainless steel solutions that ensure strength, longevity, and performance across every project.
Al Summan Metals’ Stainless Steel Flat Bars are generally made up of iron, chromium (16–20%), nickel (8–12%), manganese, silicon, and carbon (≤0.08%), varying by the particular grade (such as 304 or 316). This distinctive combination delivers exceptional corrosion resistance and durability. The bars feature tensile strength ranging from 515–620 MPa, yield strength close to 205–310 MPa, and an elongation of 40%, which results in superb toughness and formability. Having a density of about 8.0 g/cm³ and a melting point near 1400°C, they are ideal for challenging environments that call for strength, stability, and resistance to oxidation and heat.
| Specification | EN 10272, EN 10088-3 Grade 304/ 304L, 316/ 316L |
|---|---|
| Standard | API, ASME, SUS, DIN, EN, GB, UNS, ASTM, AISI |
| Sizes | 3mm to 800mm diameter |
| Length |
|
| Finish | Cold Drawn Turned, Bright Drawn, Polished, Rough Turned, Centreless Ground, Bright, Annealed, Smooth Turned, Peeled, Grinding, Black |
| Tolerances | H12, H11, K11, K12, H10, H8, H9, H13, K10, K9 |
| Surface Finish | 1D, HL, 8K, NO.4, 2D, NO.1, NO.3, 2B, BA |
| Production Method | Rolled / Forged |
| Characteristics |
|
| Value Added Services at Suraj Metal |
|
| Other available forms | Forging, Profiles, T-Bar, Rod, Hollow, Triangle, Channel, Threaded, Ingot, Rounds, Rectangle, Blocks, Billet, I/H, Half-Round, Angle, Precision-Ground |
| Port |
|
| Export to | Saudi Arabia, Peru, Italy, Malaysia, USA, Vietnam, Thailand, Egypt, Brazil, Ireland, Spain, Kuwait, Dubai, Singapore, Canada, Oman, Indonesia, Russia, Korea, Mexico, Canada, etc |
| Grade | Size in mm | Price List |
| AISI 304 | 12 x 3 | FOB Price: USA $10.39 |
| AISI 316L | 12 x 3 | FOB Price: USA $19.38 |
| AISI 316L | 12 x 5 | FOB Price: USA $19.95 |
| AISI 304 | 12 x 6 | FOB Price: USA $20.19 |
| AISI 304 | 20 x 3 | FOB Price: USA $17.12 |
| AISI 304 | 20 x 5 | FOB Price: USA $30.14 |
| AISI 316L | 20 x 5 | FOB Price: USA $31.91 |
| AISI 304 | 20 x 6 | FOB Price: USA $33.08 |
| AISI 316L | 20 x 6 | FOB Price: USA $39.23 |
| AISI 304 | 20 x 10 | FOB Price: USA $60.69 |
| AISI 304 | 20 x 15 | FOB Price: USA $62.17 |
| AISI 304 | 25 x 3 | FOB Price: USA $12.92 |
| AISI 316L | 25 x 3 | FOB Price: USA $23.61 |
| AISI 304 | 25 x 5 | FOB Price: USA $35.60 |
| AISI 304 | 25 x 6 | FOB Price: USA $45.42 |
| AISI 316L | 25 x 6 | FOB Price: USA $49.65 |
| AISI 304 | 25 x 8 | FOB Price: USA $60.29 |
| AISI 304 | 25 x 10 | FOB Price: USA $73.56 |
| AISI 316L | 25 x 10 | FOB Price: USA $55.08 |
| AISI 304 | 25 x 12 | FOB Price: USA $91.84 |
| METRIC STAINLESS STEEL FLAT BAR (mm) | IMPERIAL STAINLESS STEEL FLAT BAR | ||
|---|---|---|---|
| 8 X 5 | 50 X 12 mm | 3/8″ x 1/8″ | 1.1/2″ x 1/2″ |
| 12 X 3 | 50 X 20 mm | 1/2″ x 1/8″ | 1.1/2″ x 3/4″ |
| 12 X 6 | 50 X 25 mm | 1/2″ x 3/16″ | 1.1/2″ x 1″ |
| 12 X 10 | 50 X 40 mm | 1/2″ x 1/4″ | 1.3/4″ x 1.1/4″ |
| 15 X 3 | 60 X 3 mm | 5/8″ x 5/16″ | 2″ x 1/2″ |
| 15 X 5 | 60 X 5 mm | 3/4″ x 3/8″ | 2″ x 5/8″ |
| 15 X 6 | 60 X 6 mm | 1″ x 3/16″ | 2″ x 3/4″ |
| 15 X 10 | 60 X 8 mm | 1″ x 1/4″ | 2″ x 1.1/2″ |
| 16 X 8 | 60 X 10 mm | 1″ x 5/16″ | 2.1/2″ x 3/8″ |
| 20 X 3 | 60 X 12 mm | 1″ x 1/2″ | 2.1/2″ x 1″ |
| 20 X 5 | 60 X 15 mm | 1.1/4″ x 1/8″ | 2.1/2″ x 1.1/4″ |
| 20 X 6 | 65 X 5 mm | 1.1/4″ x 1/4″ | 3″ x 1/4″ |
| 20 X 8 | 65 X 6 mm | 1.1/4″ x 5/16″ | 3″ x 1/2″ |
| 20 X 10 | 65 X 8 mm | 1.1/4″ x 3/8″ | 3″ x 3/4″ |
| 20 X 12 | 65 X 10 mm | 1.1/4″ x 3/4″ | 3″ x 1″ |
| 25 X 3 | 65 X 12 mm | 1.1/4″ x 1″ | 4″ x 3/4″ |
| 25 X 4 | 65 X 15 mm | 1.1/2″ x 3/16″ | 4″ x 5/8″ |
| 25 X 5 | 70 X 10 mm | 1.1/2″ x 1/4″ | 4″ x 1″ |
| 25 X 6 | 75 X 3 mm | 1.1/2″ x 3/8″ | |
| 25 X 8 | 75 X 5 mm | ||
| 25 X 10 | 75 X 6 mm | ||
| 25 X 12 | 75 X 8 mm | ||
| 25 X 16 | 75 X 10 mm | ||
| 25 X 20 | 75 X 12 mm | ||
| 30 X 3 | 75 X 15 mm | ||
| 30 X 4 | 75 X 16 mm | ||
| 30 X 5 | 75 X 20 mm | ||
| 30 X 6 | 80 X 5 mm | ||
| 30 X 8 | 80 X 6 mm | ||
| 30 X 10 | 80 X 8 mm | ||
| 30 X 12 | 80 X 10 mm | ||
| 30 X 15 | 80 X 35 mm | ||
| 30 X 20 | 100 X 3 mm | ||
| 35 X 6 | 100 X 5 mm | ||
| 38 X 3 | 100 X 6 mm | ||
| 40 X 3 | 100 X 8 mm | ||
| 40 X 5 | 100 X 10 mm | ||
| 40 X 6 | 100 X 12 mm | ||
| 40 X 8 | 100 X 15 mm | ||
| 40 X 10 | 100 X 20 mm | ||
| 40 X 12 | 100 X 25 mm | ||
| 40 X 20 | 100 X 30 mm | ||
| 40 X 25 | 120 X 12 mm | ||
| 45 X 6 | 125 X 6 mm | ||
| 50 X 3 | 150 X 6 mm | ||
| 50 X 4 | 150 X 10 mm | ||
| 50 X 5 | 200 X 10 mm | ||
| 50 X 6 | 250 X 12 mm | ||
| 50 X 8 | 300 X 12 mm | ||
| 50 X 10 | |||
| FlatS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless steel flat bars can be cut with approaches such as a saw (either manual or power), angle grinders, laser cutting, or water jet cutting. Which method you pick depends on how thick the bar is, the level of precision needed, and the equipment you have on hand.
Yes, stainless steel flat bars offer strong protection against corrosion thanks to their chromium content, which creates a protective oxide layer. This layer stops rust and degradation, making stainless steel perfect for uses exposed to moisture and demanding environments.
Stainless Steel Flat Bars find broad use throughout numerous industries thanks to their strength, versatility, and resistance to wear and corrosion. Within construction, they are vital for frameworks, supports, and architectural finishes. In manufacturing, they act as raw materials for machinery parts, tools, and fasteners. The automotive and shipbuilding sectors depend on them for structural components subjected to demanding conditions. Moreover, they hold a critical part in food processing, chemical, and pharmaceutical fields where hygiene and corrosion resistance are essential. Thanks to their smooth finish and adaptability, stainless steel flat bars are likewise favored for decorative, fabrication, and maintenance uses.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Summan Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Dubai, UAE
