Al Summan Metals distinguishes itself as a top manufacturer and supplier of MP35N Bars and Rods, proudly headquartered in Dubai, UAE. They focus on high-performance nickel-cobalt-chromium-molybdenum alloy solutions designed for demanding industrial applications. The company is dedicated to precise manufacturing, strict quality control, and adherence to international standards, guaranteeing they supply materials that feature outstanding strength, corrosion resistance, and reliability. MP35N Bars and Rods are in high demand for their impressive mechanical properties, fatigue resistance, and durability, even in the most severe environments. With a firm focus on prompt delivery, competitive pricing, and excellent customer support, Al Summan Metals serves the aerospace, medical, chemical, marine, and high-performance engineering sectors with premium alloy products.
MP35N Bars and Rods are made up of nickel, cobalt, chromium, and molybdenum, a combination that delivers remarkable tensile strength, hardness, and corrosion resistance. These bars are recognized for their outstanding resistance to fatigue and stress-corrosion cracking, even under demanding conditions. MP35N retains its dimensional stability and mechanical integrity when subjected to extreme loads, temperature swings, and corrosive surroundings. The alloy can be cold worked to increase strength while still preserving its ductility and toughness. Its well-balanced composition ensures dependable performance, lasting durability, and suitability for critical applications that call for superior mechanical and chemical resistance in harsh industrial environments.
| Standards : | ASTM F562 / ASME SF562 |
| Thickness : | Range from .008″ to .0125″ |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form : | Round Bar, Wire |
| Grades | HA 190 / HA 1925 / HA 195 / HE 390 / HE 3925 / HE 395 / HE 397 |
|
Cr |
20 nom |
|
Ni |
35 nom |
|
Mo |
10 nom |
|
Co |
35 nom |
| Material | Condtion | Ultimate Tensile Strength ksi | 0.2 % Yield Strength ksi | Elongation % | Reduction of Area % | Hardness HRC |
| MP35N AMS 5844 | Solution Heat Treated and Work Strengthened | 255 | 225 | 12 | 50 | 45 |
| MP35N AMS 5845 | Solution Heat Treated and Work Strengthened and Aged | 260 | 230 | 8 | 35 | 38 min |
| PHYSICAL PROPERTIES | ||||||
|---|---|---|---|---|---|---|
| Density | Electrical conductivity (% IACS) | Thermal conductivity (BTU-in/hr-ft²-°F) | Specific heat capacity | Thermal expansion (1/°F) | Melting Point (°F) | |
| 0..305 | 1.67 | 78 | 0.12 | 0.00000711 | 2510 | |
MP35N bars are indeed recyclable once they have been used. Being a high-performance alloy, it can be melted and repurposed to create new components without any major reduction in quality.
MP35N rods come in sizes determined by their diameter and length, generally spanning from 1/16" to 6" diameter with custom lengths, based on application needs and manufacturing specifications.
MP35N rods come in a range of dimensions, generally from 1/8" up to 8" in diameter. Typical surface treatments include cold drawn, hot rolled, and annealed to improve machinability and surface finish.
MP35N Bars and Rods are widely applied in industries that demand materials offering high strength, resistance to corrosion, and long fatigue life. They frequently appear in medical devices, surgical instruments, and implantable components owing to their biocompatibility and corrosion resistance. Within the aerospace and chemical sectors, MP35N serves in springs, fasteners, shafts, and other vital load-bearing parts. This alloy is likewise well suited for marine equipment, high-performance machinery, and oil and gas applications where extreme stress and corrosive conditions pose challenges.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
