Al Summan Metals, a top manufacturer and supplier headquartered in Dubai, UAE, focuses on producing and delivering high-quality alloy steel products, such as the widely sought-after 20MnCr5 Round Bars. Supported by state-of-the-art production facilities and a strong dedication to global quality standards, Al Summan Metals ensures that their materials deliver outstanding performance, longevity, and accuracy. They serve a broad spectrum of industries, ranging from automotive and engineering to machinery and power generation. Known for their reliability and technical know-how, Al Summan Metals consistently provides 20MnCr5 Round Bars that meet the rigorous demands of today’s industrial applications, both across UAE and internationally.
20MnCr5 Round Bars are low-alloy case-hardening steels consisting of approximately 0.17–0.22% carbon, 1.1–1.4% manganese, 0.9–1.2% chromium, along with trace amounts of silicon and sulfur. This specific composition strikes an optimal balance between core toughness and surface hardness after the carburizing process. The material delivers remarkable mechanical properties, featuring a tensile strength ranging from 550 to 850 MPa, as well as good ductility and high wear resistance. 20MnCr5 maintains its structural integrity even when placed under stress, making it an excellent choice for components that need both a hard surface and a resilient core to enhance fatigue performance.
|
Element |
Content |
|---|---|
|
Carbon, C |
0.310 – 0.380 % |
|
Iron, Fe |
98.63 – 99.09 % |
|
Manganese, Mn |
0.60 – 0.90 % |
|
Phosphorous, P |
0.040 % |
|
Sulfur, S |
0.050 % |
|
Properties |
Metric |
Imperial |
|---|---|---|
|
Tensile strength, ultimate |
585 MPa |
84800 psi |
|
Tensile strength, yield |
370 MPa |
53700 psi |
|
Modulus of elasticity |
190-210 GPa |
29700-30458 ksi |
|
Bulk modulus (typical for steel) |
140 GPa |
20300 ksi |
|
Shear modulus (typical for steel) |
80 GPa |
11600 ksi |
|
Poissons ratio |
0.27-0.30 |
0.27-0.30 |
|
Elongation at break (in 50 mm) |
30% |
30% |
|
Reduction of area |
53% |
53% |
|
Hardness, Brinell |
183 |
183 |
|
Hardness, Knoop (converted from Brinell hardness) |
204 |
204 |
|
Hardness, Rockwell B (converted from Brinell hardness) |
89 |
89 |
|
Hardness, Vickers (converted from Brinell hardness) |
192 |
192 |
|
Machinability (based on AISI 1212 steel. as 100 machinability) |
65 |
65 |
| EN Name | EN Number | DIN | JIS | UNI | BS |
|---|---|---|---|---|---|
| C35 | 1.0501 | C35, CM35 | S35C | C35 | 970 070M36 |
Yes, 20MnCr5 Round Bars work well for underground applications owing to their high strength and durability.
Yes, 20MnCr5 Round Bars might require corrosion protection coatings to enhance their durability in harsh environments.
Choose 20MnCr5 Round Bars based on the strength needed, wear resistance, and the particular environmental conditions of the application.
Across the engineering and automotive sectors, 20MnCr5 Round Bars find broad use in parts that demand high surface hardness combined with core strength. They are perfect for manufacturing gears, shafts, crankshafts, camshafts, couplings, and fasteners. Thanks to the steel’s outstanding machinability and wear resistance, it suits applications that involve heavy loads and friction. In machinery and power transmission systems, 20MnCr5 guarantees a long service life and dependable performance, even under challenging operating conditions. Al Summan Metals’ 20MnCr5 Round Bars provide high-quality, economical material solutions for precision-engineered and high-performance industrial components.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
