Al Summan Metals, a leading manufacturer and supplier based in Dubai, UAE, is renowned for producing high-quality Alloy Steel Hex Bars built for strength, precision, and reliability. Through advanced manufacturing methods and stringent quality control, Al Summan Metals reliably provides products that meet global performance and durability standards. Their Alloy Steel Hex Bars are recognized for their remarkable toughness, wear resistance, and machinability. Serving a range of industries such as automotive, construction, oil and gas, and engineering, Al Summan Metals ensures superior product quality and enduring performance, even in the toughest industrial environments.
These Alloy Steel Hex Bars are composed of carbon (0.20–0.40%), chromium (0.8–1.2%), molybdenum (0.15–0.25%), manganese (0.5–1.0%), and nickel (up to 1.0%). This particular alloy composition enhances hardness, tensile strength, and corrosion resistance. Mechanically, alloy steel exhibits a tensile strength between 600–900 MPa and a yield strength of roughly 400 MPa, which may differ depending on heat treatment. These bars are recognized for their outstanding toughness, ductility, and machinability, making them ideal for components subjected to high stress, fatigue, and heavy mechanical loads.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Range | 5mm to 500mm Dia in 100mm to 6000mm Length |
| Diameter | 10 mm To 200 mm |
| Thickenss | 0.5mm to 500mm Diameter |
| High Speed Steel (HSS), HCHCR & OHNS in Grade | M2, M3, M35, M42, T-1, T-4, T-15, T-42, D2, D3, H11, H13, OHNS-01 & EN52 |
| Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | 1000 mm Long To 6000 mm Long |
| Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Element | C | Cr | Mn | Mo | P | S | Si | Ni |
| F5 | 0.15 Max | 4.0-6.0 | 0.30-0.60 | 0.44-0.65 | 0.035 Max | 0.030 Max | 0.50 Max | 0.50 Max |
| F1 | 0.15 Max | 3.0-5.0 | 0.30-0.60 | 0.40-0.50 | 0.035 Max | 0.030 Max | 0.50 Max | 0.50 Max |
| F22 | 0.05-0.15 | 2.00-2.50 | 0.30-0.60 | 0.90-1.10 | 0.035 Max | 0.040 Max | 0.50 Max | – |
| F91 | 0.08-0.12 | 8.0-9.5 | 0.30-0.60 | 0.85-1.05 | 0.020 Max | 0.010 Max | 0.20-0.50 | 0.40 Max |
| F9 | 0.15 Max | 8.0-10.0 | 0.30-0.60 | 0.90- 1.10 | 0.030 Max | 0.030 Max | 0.50- 1.00 | – |
| F11 | 0.10-0.20 | 1.00-1.50 | 0.40-0.65 | 0.44-0.65 | 0.025 Max | 0.040 Max | 0.50-0.80 | – |
| Grade | Tensile Strength (ksi) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (ksi) min |
| F9 | 415 | 30 | 205 |
| F5 | 275 | 485 | 20 |
| Size (mm) | Weight (kg/m) | Size (mm) | Weight (kg/m) | Size (mm) | Weight (kg/m) |
| 7 x 7 | 0.337 | 19 x 19 | 2.479 | 38 x 38 | 9.916 |
| 8 x 8 | 0.44 | 20 x 20 | 2.747 | 40 x 40 | 10.988 |
| 9 x 9 | 0.556 | 21 x 21 | 3.029 | 42 x 42 | 12.114 |
| 10 x 10 | 0.687 | 22 x 22 | 3.324 | 45 x 45 | 13.906 |
| 11 x 11 | 0.831 | 24 x 24 | 3.956 | 48 x 48 | 15.822 |
| 12 x 12 | 0.989 | 25 x 25 | 4.292 | 50 x 50 | 17.168 |
| 13 x 13 | 1.161 | 26 x 26 | 4.642 | 53 x 53 | 19.29 |
| 14 x 14 | 1.346 | 28 x 28 | 5.384 | 55 x 55 | 20.774 |
| 15 x 15 | 1.545 | 30 x 30 | 6.181 | 60 x 60 | 24.723 |
| 16 x 16 | 1.758 | 32 x 32 | 7.032 | 65 x 65 | 29.015 |
| 17 x 17 | 1.985 | 34 x 34 | 7.939 | 70 x 70 | 33.65 |
| 18 x 18 | 2.225 | 36 x 36 | 8.9 | 75 x 75 | 38.629 |
Alloy steel hex bars are produced through hot rolling or forging of alloy steel billets, then followed by precision machining, annealing, and surface finishing to reach the intended size, strength, and quality.
Alloy steel hex bars and rods achieve the best corrosion resistance through finishes such as zinc plating, chrome plating, electropolishing, and black oxide coating, along with the use of epoxy or powder coatings for added protection.
Alloy Steel Hex Bars are widely used in engineering, automotive, and machinery manufacturing thanks to their outstanding strength and versatility. They are commonly employed to produce fasteners, shafts, couplings, bolts, nuts, and connecting rods. Their exceptional hardness and corrosion resistance make them well suited for marine, oil and gas, and power generation applications. In addition, Alloy Steel Hex Bars are frequently the preferred option for precision components in tools, construction equipment, and heavy-duty machinery, where durability and dimensional accuracy are critical for dependable, long-term performance.
We provide products that come with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
