Al Summan Metals, a premier manufacturer and supplier based in Dubai, UAE, is recognized for producing high-quality Aluminium 1060 Bars and Rods. These products are valued for their exceptional corrosion resistance, notable ductility, and superior surface finish. With advanced manufacturing technology and stringent quality control, Al Summan Metals ensures that every product meets international standards, delivering dependable performance across a variety of industrial applications. Lightweight yet strong, Aluminium 1060 Bars and Rods offer excellent workability and conductivity. They serve numerous sectors, including chemical, food processing, construction, and electrical, offering precision-engineered aluminium solutions that combine strength, versatility, and durable performance for demanding uses.
Aluminium 1060 Bars and Rods are made up of roughly 99.6% aluminium, containing only trace levels of iron, silicon, and copper as impurities. This high-purity composition delivers outstanding corrosion resistance, excellent thermal and electrical conductivity, and superior formability. When it comes to mechanical properties, 1060 aluminium offers a tensile strength of about 90–110 MPa, yield strength of 35–55 MPa, and elongation of 25–35%. The material is recognized for its excellent ductility, weldability, and ease of machining, making it ideal for applications that call for lightweight, durable, and easily fabricated aluminium components.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Aluminium 1060 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.15 – 0.20 | 0.10 – 0.15 | 0.01 – 0.03 | 0.01 – 0.03 | 0.01 – 0.05 | 0.01 – 0.03 | 0.020 – 0.030 | 99.60 |
| Mechanical Properties – Al 1060 | |||||||||||||||||||
| Alloy | Temper | UTS(Mpa) | % Elongation | ||||||||||||||||
| Min | Max | 0.5 mm -0.8 mm | 0.81 mm – 1.30 mm | 1.30 mm – above | |||||||||||||||
| 1060 | O | 55 | 75 | 25 | 25 | 30 | |||||||||||||
| H12 | 75 | 110 | 6 | 6 | 7 | ||||||||||||||
| H14 | 90 | 120 | 5 | 5 | 6 | ||||||||||||||
| H16 | 95 | 130 | 4 | 4 | 4 | ||||||||||||||
| H18 | 130 | — | 3 | 3 | 3 | ||||||||||||||
| STANDARD | UNS | DIN |
| Aluminium 1060 | A91060 | – |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 1060 bars offer resistance to corrosion. Because of its high purity, this alloy naturally develops a protective oxide layer across its surface, which aids in resisting corrosion caused by moisture and environmental factors.
Yes, the size and length of Aluminium 1060 rods can be customized. Manufacturers generally provide customization to satisfy the specific needs of various industrial applications, guaranteeing exact dimensions and optimal performance.
Yes, Aluminium 1060 bars are recyclable once they have been used. Aluminium can be recycled without any loss to its properties, which makes it an environmentally friendly material suitable for reuse many times across a range of applications.
These Aluminium 1060 Bars and Rods are widely used across industries that require high-purity, corrosion-resistant, and lightweight materials. Common applications include chemical processing equipment, food and beverage machinery, roofing and siding, decorative panels, and electrical conductors. Thanks to their remarkable resistance to oxidation and atmospheric corrosion, they are also employed in heat exchangers, storage tanks, pressure vessels, and architectural components. With their exceptional workability, strength, and versatility, Aluminium 1060 Bars and Rods are well suited for producing both functional and structural components in aerospace, marine, and electrical applications.
We provide products that come with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
