Al Summan Metals, based in Dubai, UAE, distinguishes itself as a leading manufacturer and supplier of Aluminium 2017 Forgings. These forgings are renowned for their remarkable strength, superb machinability, and exceptional resistance to corrosion. The company focuses on producing precision-engineered forgings that comply with international standards, ensuring dependable quality and reliability. They provide Aluminium 2017 Forgings in an assortment of shapes and sizes to serve a broad spectrum of industrial requirements, particularly in the aerospace, automotive, and defense sectors. By combining advanced forging technology with stringent quality control, Al Summan Metals delivers durable, lightweight, and high-performance components capable of withstanding demanding operational conditions and critical applications, fostering innovation and efficiency throughout diverse industries.
Aluminium 2017 Forgings are chiefly produced from aluminum alloyed with copper, which acts as the primary strengthening element, together with small quantities of manganese, magnesium, and iron. This distinctive composition gives the alloy high tensile and yield strength, exceptional hardness, and good fatigue resistance. Aluminium 2017 is also readily heat-treatable, improving its mechanical properties and making it ideal for precision machining and structural applications. Its combination of strength, toughness, and corrosion resistance guarantees reliable performance even in demanding environments, making Aluminium 2017 Forgings a preferred choice for high-stress applications.
Standards :ASTM B247, B247
Temper :T6 T651 T6511
Specification :DIN, ASTM, BS and every International Standard
Flat bar blocks :up to 27″ width and 15,000 lbs.
Cylinders and sleeves :up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs :up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings :up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts :up to 144″ maximum length and 20,000 lbs.
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others Each | Other Total |
| 2017 | Rem | 0.20-0.8 | 0.7 max | 3.5-4.5 | 0.40-1.0 | 0.40-0.8 | 0.10 max | 0.25 max | 0.15 max | 0.05 max | 0.15 max |
| Material | Condition | Tensile Strength (N/mm²) min | Yield Strength | Elongation in 4D % | ||
| ksi | Mpa | ksi | Mpa | |||
| 2017 | 2017-T4 Bar | 55 | 379 | 32 | 221 | 12 |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4MgSi | AU4G | 3.1325 | A92017 | AlCu4MgSi | 2017 | AlCuMg1 |
Aluminum 2017 works well for forging but offers limited resistance to high temperatures. For forging tasks that involve high temperatures, look into alloys with improved heat resistance, such as 2219 or 2618.
Aluminum 2017 provides high strength, excellent machinability, good corrosion resistance, and easy welding, making it ideal for custom forgings in aerospace, military, and high-performance applications.
These forgings are widely used in aerospace structures, including aircraft components, fuselage sections, and wing assemblies, owing to their outstanding strength-to-weight ratio. They are also employed in automotive parts, defense equipment, and high-performance industrial machinery where durability and precision are essential. The alloy’s excellent machinability enables the production of complex shapes and intricate designs, such as shafts, fittings, and gears. Aluminium 2017 Forgings provide long-lasting performance in high-stress conditions, making them essential for industries that demand lightweight, strong, and reliable components.
We provide products supplied with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
