Al Summan Metals, based in Dubai, UAE, has established a strong reputation as a dependable manufacturer and supplier of premium Aluminium 2024 Bars and Rods. Known for their precision, strength, and dedication to international standards, Al Summan Metals produces aluminium products that are ideal for high-performance applications. Aluminium 2024, composed mainly of aluminium with copper serving as its primary alloying element, is valued for its outstanding strength, fatigue resistance, and machinability. Through advanced manufacturing methods and stringent quality control, Al Summan Metals ensures that its Aluminium 2024 Bars and Rods provide reliable and durable performance across a range of industries, including aerospace, automotive, defense, and engineering.
These Aluminium 2024 Bars and Rods are composed primarily of aluminium, together with 3.8–4.9% copper, 1.2–1.8% magnesium, 0.3–0.9% manganese, and trace quantities of other elements. This distinctive combination produces high tensile strength, remarkable fatigue resistance, and moderate corrosion resistance. Regarding mechanical properties, the alloy offers a tensile strength of approximately 415–480 MPa, a yield strength of 325–350 MPa, and good elongation, making it well suited for structural, machining, and high-stress applications where a strong strength-to-weight ratio is essential.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 2024 | A92024 | 3.1355 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 2024 can be welded, though it presents difficulties because of its tendency to crack. For the best outcomes, specialized methods such as TIG welding with the correct filler material and preheating are recommended.
To maintain Aluminium 2024 bars, clean them regularly with a mild detergent, keep them away from harsh chemicals, and apply protective coatings. Store them in dry conditions to prevent moisture and corrosion, ensuring longevity.
Yes, Aluminium 2024 is capable of corroding, particularly in harsh environments. While it offers moderate corrosion resistance, its vulnerability rises when proper protective coatings are absent, leaving it prone to pitting and stress corrosion cracking.
Aluminium 2024 Bars and Rods are widely used in industries that require high strength and durability. They are ideal for aerospace structural components, aircraft fittings, automotive frames, and defense equipment. In addition, they are employed in high-performance machinery, precision instruments, and industrial components where fatigue resistance and structural integrity are essential. Owing to their excellent machinability and impressive strength-to-weight ratio, Aluminium 2024 Bars and Rods are the preferred choice for demanding engineering and industrial applications.
We provide products supplied with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
