Al Summan Metals, based in Dubai, UAE, has established a strong reputation as a trustworthy manufacturer and supplier of high-quality metal products, including Aluminium 3003 Bars and Rods. The company distinguishes itself through its advanced production techniques, strict quality control, and commitment to supplying materials that meet international standards. The Aluminium 3003 Bars and Rods offered by Al Summan Metals are renowned for their remarkable corrosion resistance, superb formability, and moderate strength, making them ideal for a broad spectrum of industrial applications. Serving industries such as construction, chemical processing, HVAC, food processing, and general engineering, Al Summan Metals provides reliable, long-lasting, and high-performance aluminium solutions designed to satisfy the specific requirements of its customers.
These Aluminium 3003 Bars and Rods are mainly produced from an aluminium alloy containing roughly 1.2% manganese, which enhances their strength, corrosion resistance, and workability. They display mechanical properties such as a tensile strength between 110 and 200 MPa, a yield strength of around 40 to 150 MPa, and an elongation of 10 to 35%, varying with the temper. This alloy is recognized for its excellent formability, good fatigue resistance, and remarkable performance in both atmospheric and chemical environments. On top of that, it welds and machines easily, making it well suited for applications that call for durable, lightweight, and corrosion-resistant components.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Cr | Cu | Fe | Mg | Mn | Other Total | Si | Ti | Zn |
| min. | Remainder | – | 0.05 to 0.20% | 0.7% | – | 1.0 to 1.5% | 0.15% | 0.6% | – | 0.10% |
| Properties | Metric | Imperial |
| Tensile strength | 130 MPa | 18855 psi |
| Yield strength | 125 MPa | 18130 psi |
| Shear strength | 83 MPa | 12039 psi |
| Fatigue strength | 55 MPa | 7977 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 10% | 10% |
| Hardness | 35 | 35 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 3003 | A93003 | 3.0517 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 3003 bars can be joined through conventional welding methods, including TIG or MIG welding. Their outstanding corrosion resistance and weldability make them well suited for a wide range of applications.
Yes, Aluminium 3003 bars and rods are well-suited for hygienic and sanitary applications thanks to their resistance to corrosion, lightweight nature, and excellent capacity to endure moisture and chemical exposure.
Aluminium 3003 bars offer excellent corrosion resistance thanks to their manganese content, which makes them highly resistant to rust and chemical exposure in most environments, including marine and industrial settings.
Aluminium 3003 Bars and Rods are widely used across a range of industries, such as construction, food and beverage processing, HVAC systems, chemical storage, and general fabrication. Owing to their corrosion resistance and formability, they are especially well-suited for producing heat exchangers, kitchen equipment, fuel tanks, storage tanks, roofing sheets, piping systems, and architectural fittings. Their lightweight nature and durability also make them an excellent choice for transportation equipment and sheet metal work. Thanks to their versatility and reliability, Aluminium 3003 Bars and Rods have become a preferred option for industries requiring long-lasting, easy-to-fabricate, and corrosion-resistant materials.
We provide products supplied with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Summan Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Dubai, UAE
