Al Summan Metals, headquartered in Dubai, UAE, has established a strong reputation as a manufacturer and supplier of premium Aluminium 6063 Forgings. These forgings are renowned for their outstanding finish, precision, and durability. The company is committed to delivering forging solutions that meet international standards, serving a broad spectrum of industrial needs. With advanced production technologies and stringent quality control, Al Summan Metals ensures that its Aluminium 6063 Forgings offer excellent mechanical performance and corrosion resistance. They cater to numerous sectors, such as construction, automotive, transportation, structural engineering, and consumer products, providing customized sizes, shapes, and specifications to satisfy both lightweight and strong structural demands.
Aluminium 6063 Forgings are made primarily of aluminum, with magnesium and silicon serving as the main alloying elements that increase strength and improve formability. These forgings are recognized for their good tensile strength, excellent corrosion resistance, and smooth surface finish. They offer a balance of moderate hardness and good weldability, which makes them ideal for producing complex and precise shapes. In addition, Aluminium 6063 demonstrates impressive extrudability, enabling a wide variety of profile designs. Its mechanical properties provide durability while keeping the material lightweight, making it an excellent choice for structural and architectural applications.
Standards :ASTM B247, B247
Temper :H14
Specification :DIN, ASTM, BS and all International Standards
Flat bar blocks :up to 27″ width and 15,000 lbs.
Cylinders and sleeves :up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs :up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings :up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts :up to 144″ maximum length and 20,000 lbs.
| Cu | Si | Fe | Mn | Mg | Zn | Cr | Ti | Al | Other Each | Others Total |
| .10 (max) | .20/.60 | .35 (max) | .10 (max) | .45/.90 | .10 (max) | .10 (max) | .10 (max) | Remainder | .05 | .015 |
| Tensile Strength (psi) | Yield Strength (psi) | Elongation (% in 2″) | Brinell Hardness |
| 27,000 | 21,000 | 12 | 60 |
| UNS | WNR | DIN | EN | ISO | BS (OLD) | USA |
| A96063 | 3.32206 | AlMgSi0.5 | AW-AlMg0,7Si EN AW-6063 | AlMg0,7Si | HE9 | AA6063 |
Aluminum 5082 provides high strength, outstanding corrosion resistance, good weldability, and improved fatigue resistance, making it well suited for custom forgings in marine, aerospace, and structural applications.
Aluminum 5082's workability, marked by good machinability and medium strength, permits easy shaping during forging. However, its relatively low work hardening rate may call for careful temperature control.
You’ll come across Aluminium 6063 Forgings in a wide range of applications, spanning construction and architectural frameworks, transportation components, furniture manufacturing, electrical fittings, and industrial equipment. Their outstanding corrosion resistance and appealing finish make them ideal for window frames, door frames, railings, and curtain walls. Within the automotive and transportation sectors, they assist in reducing vehicle weight without sacrificing structural integrity. They are also employed in heat sinks, marine hardware, and a variety of precision-engineered components. Industries prefer Aluminium 6063 Forgings for their distinctive combination of strength, formability, and lightweight properties.
We provide products supplied with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
