Al Summan Metals, a top manufacturer and supplier based in Dubai, UAE, focuses on producing high-strength Aluminium 7050 Bars and Rods built to perform in demanding industrial environments. Through advanced production techniques and strict quality inspections, Al Summan Metals ensures that every product satisfies international standards for strength, durability, and corrosion resistance. Aluminium 7050 Bars and Rods are known for their remarkable mechanical properties, featuring high tensile strength and fatigue resistance. Serving sectors such as aerospace, defense, automotive, and construction, Al Summan Metals delivers precision-engineered aluminium solutions that combine lightweight characteristics with lasting reliability and exceptional performance, even under the toughest conditions.
These Aluminium 7050 Bars and Rods consist of roughly 6.2–6.7% zinc, 2.1–2.6% magnesium, 2.0–2.6% copper, and 0.12% chromium, with aluminium making up the remainder. This distinctive blend provides them with outstanding strength, hardness, and superb resistance to stress corrosion cracking. In terms of mechanical properties, 7050 aluminium displays a tensile strength of about 540–600 MPa, yield strength of 470–520 MPa, and an elongation of 11–15%. On top of that, it delivers excellent fatigue resistance, fracture toughness, and machinability, which makes it a leading option for high-performance structural and aerospace applications.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight % | Zn | Cu | Mg | Zr | Fe | Si | Mn | Ti | Cr | Others (total) |
| Minimum | 5.7 | 2.0 | 1.9 | 0.08 | – | – | – | – | – | – |
| Maximum | 6.7 | 2.6 | 2.6 | 0.15 | 0.15 | 0.12 | 0.10 | 0.06 | 0.04 | 0.15 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 515 MPa | 74695 psi |
| Yield strength | 455 MPa | 65992 psi |
| Fatigue strength | 240 MPa | 34809 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 11% | 11% |
| UNS | EN | DIN,WNr | ISO |
| A97050 | EN3982 | 3.4144 | AlZn6CuMgZr |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 7050 bars are excellent for structural applications, especially within the aerospace and military sectors, delivering high strength, corrosion resistance, and fatigue resistance, which makes them well suited for demanding environments and designs.
To maintain Aluminium 7050 bars, clean them regularly with mild soap and water to remove dirt and debris. Steer clear of harsh chemicals, check for corrosion, and keep them stored in a cool, dry environment.
Yes, Aluminium 7050 rods are highly recyclable. Aluminium, including alloy 7050, can be recycled numerous times without any loss of its properties, making it an eco-friendly option for sustainable manufacturing and use.
Aluminium 7050 Bars and Rods are widely used across the aerospace, defense, automotive, and high-performance engineering sectors thanks to their exceptional strength-to-weight ratio and resistance to corrosion. They are ideal for producing aircraft structural components, fuselage frames, wing spars, bulkheads, and landing gear parts. Beyond that, they are applied in automotive chassis, high-performance machinery, and marine settings where durability, fatigue resistance, and lightweight characteristics are crucial. Featuring excellent machinability and heat-treatable qualities, Aluminium 7050 Bars and Rods provide dependable performance across a range of demanding applications.
We provide products supplied with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
