Al Summan Metals, headquartered in Dubai, UAE, has earned a strong reputation as a manufacturer and supplier of premium Aluminium 7075 Bars and Rods. The company takes pride in providing high-quality materials that satisfy the demanding standards of numerous industries. Well known for their outstanding strength, precision, and durability, Al Summan Metals caters to a broad spectrum of sectors that depend on lightweight and reliable metal solutions. The company puts a strong focus on quality assurance, guaranteeing precise material composition and on-time delivery to serve the aerospace, defense, automotive, and engineering fields.
With a commitment to customer satisfaction and compliance with international standards, Al Summan Metals provides Aluminium 7075 Bars and Rods that perform exceptionally well in high-stress and critical applications.
Aluminium 7075 Bars and Rods are made mainly of aluminium, with zinc serving as the primary alloying element, together with small quantities of magnesium, copper, and chromium. This distinctive blend endows the material with impressive tensile strength, excellent fatigue resistance, and outstanding hardness. Relative to many other aluminium grades, Aluminium 7075 offers superior mechanical properties while remaining comparatively lightweight. It can also undergo heat treatment to enhance its performance and is recognised for its good machinability. That said, its corrosion resistance is moderate, so it is wise to apply protective coatings in environments that demand added durability.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight % | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Each | Total |
| Minimum | 1.20 | 2.10 | 0.18 | 5.10 | ||||||
| Maximum | 0.40 | 0.50 | 2.00 | 0.30 | 2.90 | 0.28 | 6.10 | 0.20 | 0.05 | 0.15 |
| Temper | Tensile | Hardness | ||||
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6, T651 | 83 | 572 | 73 | 503 | 11 | 150 |
| T73, T7351 | 73 | 503 | 63 | 434 | 13 | N/A |
| UNS | EN | DIN,WNr | JIS | AFNOR | ISO | BS | GOST |
| A97075 | ENAW-AlZn5.5MgCu EN AW-7075 | 3.4365 AlZnMgCu1.5 | 7075 | 7075 A-Z5GU | AlZn6MgCu | 7075 L95 L96 | V95 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 7075 bar is widely used for structural applications thanks to its high strength, excellent corrosion resistance, and lightweight properties, which make it well suited for aerospace, automotive, and military structural components.
Aluminium 7075 rods are dimensioned according to their diameter and length. Diameters generally span from 1/8" to 12", while lengths range from 3' to 20', based on the particular needs of each customer.
To maintain Aluminium 7075 bar, clean it regularly with mild soap and water to remove dirt. Steer clear of harsh chemicals, and keep it stored in a cool, dry environment to prevent corrosion and damage.
These Aluminium 7075 Bars and Rods are highly desired in applications requiring a high strength-to-weight ratio and exceptional mechanical stability. They are broadly utilized across the aerospace and aviation sectors for aircraft fittings, structural components, and frames. Within the automotive and motorsport industries, they are employed in high-performance engine parts, drive shafts, and suspension components. Defense uses encompass weapon parts, armor plate fittings, and tactical gear. Moreover, these rods are favored in sports equipment, including bicycle frames, climbing gear, and archery components, where strength, reliability, and performance are essential.
We provide products that come with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
