Al Summan Metals, based in Dubai, UAE, has built a strong reputation as a trustworthy manufacturer and supplier of top-quality **Beryllium Copper C17500 Bars and Rods**. Known for their precision and long service life, Al Summan Metals complies with international standards, manufacturing copper-beryllium products designed for high-performance applications. The Beryllium Copper C17500 alloy is a precipitation-hardened formulation that offers exceptional strength, superior electrical and thermal conductivity, and considerable resistance to corrosion and wear. Through the use of cutting-edge manufacturing methods and stringent quality control, Al Summan Metals ensures that its Beryllium Copper C17500 Bars and Rods provide reliable, sturdy, and enduring performance across numerous industries, including aerospace, electrical, automotive, and industrial applications.
These Beryllium Copper C17500 Bars and Rods are made mostly of copper with 1.8–2.0% beryllium, plus minor quantities of cobalt or nickel added to enhance their mechanical characteristics. This distinctive makeup delivers remarkable hardness and tensile strength (climbing to as much as 1,400 MPa following age hardening) while continuing to offer good electrical and thermal conductivity. The alloy further demonstrates outstanding fatigue, wear, and corrosion resistance, which makes it a strong fit for parts that need to withstand tough conditions over the long term.
Material:Beryllium
Outer Diameter:0.060-2.00mm
Type:Copper Alloys
Standard:UNS C17500
Processing:Seamless / Welded
| Element | Be | Co | Ni | Co+Ni | Co+Ni+Fe | Pb | Al | Si | Fe | Cu |
|---|---|---|---|---|---|---|---|---|---|---|
| Beryllium C17500 | 0.4-0.7 | 2.4-2.7 | – | – | – | – | 0.2 max. | 0.2 max. | 0.1 max. | Bal |
| Element | Density (g/cm3) | Elastic Modulus(MPA) | Thermal Expansion | Thermal Conductivity(w/(m.k) | Melting Temperature(C) |
|---|---|---|---|---|---|
| Beryllium C17500 | 8.83 | 138000 | 18 | 240 | 1010-1050 |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Alloy No. 10 | 2.1285 | C17500 |
| Alloy No. 3 | 2.0850 | C17510 |
Yes, Beryllium Copper C17500 can be recycled. It is possible to melt it down and reuse it in manufacturing, cutting down the demand for new raw materials while retaining its properties after the recycling process.
Beryllium Copper C17500 rods can indeed be tailored in both dimensions and length to meet particular requirements. Manufacturers generally provide customization options to suit a range of industrial uses.
Yes, Beryllium Copper C17500 bars offer strong resistance to corrosion, particularly in harsh environments, thanks to their durable alloy makeup. That said, they become more susceptible to corrosion under chloride-heavy conditions.
Beryllium Copper C17500 Bars and Rods are employed in numerous applications that call for a combination of high strength, electrical conductivity, and corrosion resistance. They are especially well suited for precision springs, connectors, electrical contacts, aerospace components, and tooling used in die-casting and extrusion processes. In addition, they cater to the oil and gas, marine, and automotive industries, where strength, wear resistance, and reliability are essential. Thanks to their distinctive mix of mechanical and electrical properties, Beryllium Copper C17500 Bars and Rods are the favored option for demanding engineering and industrial applications.
We provide products backed by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
