Al Summan Metals, a leading manufacturer and supplier based in Dubai, UAE, is dedicated to producing high-quality C35 Round Bars engineered for strength, durability, and precision. With advanced manufacturing facilities and a stringent quality control process, Al Summan Metals ensures that its products not only comply with international standards but also provide dependable performance across a variety of industrial applications. C35 Round Bars are crafted from medium-carbon steel, renowned for their remarkable hardness, tensile strength, and wear resistance. Owing to the company’s steadfast dedication to quality and reliability, these bars are ideal for industries such as automotive, machinery, construction, and general engineering, ensuring strong performance even in demanding environments.
C35 Round Bars are made of medium-carbon steel containing roughly 0.32–0.40% carbon, 0.50–0.80% manganese, together with trace levels of phosphorus and sulfur. This composition produces a balanced combination of strength, hardness, and toughness. In terms of mechanical properties, C35 steel offers a tensile strength of about 600–700 MPa and a yield strength of around 350–400 MPa. It is recognized for good machinability, moderate ductility, and excellent wear resistance, which makes it a strong candidate for heat treatment to enhance hardness and strength for demanding applications.
|
Variant |
Cast |
Di |
Weldability |
C % |
Si % |
Mn % |
P % |
S % |
Cr % |
Ni % |
|
|---|---|---|---|---|---|---|---|---|---|---|---|
|
C35E |
CC |
0.98 |
CEV 0.65max |
Min |
0.35 |
0.15 |
0.50 |
– |
0.015 |
– |
– |
|
Pcm 0.49max |
Max |
0.39 |
0.35 |
0.80 |
0.030 |
0.035 |
0.30 |
0.30 |
| Variant | Condition | Format | Dimension [mm] | Yield strength min [MPa] | Tensile strength [MPa] | Elongation A5[%] | Hardness | Impact (ISO-V) strengthmin |
|---|---|---|---|---|---|---|---|---|
| Rp0.2 * Reh, ** Rel | ||||||||
| C35E | +AR | Round bar | < 20 | 345* | 520-690 | 10 | < 230 HB | 0 °C 0 J (long) 0 |
| EN | C35 (1.0501) |
| DIN | C35, CM35 |
| BS | 970 070M36 |
| UNI | C35 |
| JIS | S35C |
Considerations when installing C35 Round Bar include making sure of proper alignment, sufficient support, correct machining, and compliance with safety and load-bearing requirements.
Yes, C35 Round Bar is weldable, though it needs proper preheating and post-weld heat treatment to prevent brittleness. Selecting the right welding electrodes is also crucial for producing strong, durable welds.
C35 Round Bar comes in a range of sizes, generally spanning from 10 mm to 250 mm in diameter, with custom dimensions available on request.
These C35 Round Bars are used across a range of sectors, including automotive, mechanical, and general engineering, where they serve to manufacture components that must be strong and wear-resistant. You’ll frequently find them in applications such as shafts, bolts, studs, pins, axles, crankshafts, and various machinery parts. They’re also employed in agricultural equipment, construction machinery, and forging operations where toughness and dimensional stability are critical. Owing to their responsiveness to heat treatment and machining, C35 Round Bars are ideal for producing precision-engineered components that deliver long-lasting performance under high stress and operational loads.
We provide products supplied with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
