Al Summan Metals, headquartered in Dubai, UAE, distinguishes itself as a leading manufacturer and supplier of premium Carbon Steel Rectangular Bars and Rods. Recognized for their precise engineering and long-lasting quality, they rigorously follow international standards, guaranteeing that their products are ideal for challenging industrial and engineering applications. The Carbon Steel Rectangular Bars and Rods they provide feature remarkable strength, superb machinability, and outstanding wear resistance, making them a great fit for heavy-duty and high-stress settings. Through cutting-edge manufacturing methods, thorough quality control, and timely delivery, Al Summan Metals ensures that every product offers dependable performance, an extended service life, and outstanding value for industries within UAE and across the world.
Al Summan Metals, headquartered in Dubai, UAE, distinguishes itself as a leading manufacturer and supplier of premium Carbon Steel Rectangular Bars and Rods. Renowned for their precise engineering and long-lasting quality, they firmly comply with international standards, guaranteeing that their products are ideal for challenging industrial and engineering applications. The Carbon Steel Rectangular Bars and Rods they provide feature remarkable strength, superb machinability, and outstanding wear resistance, making them a good fit for heavy-duty and high-stress settings. Owing to cutting-edge manufacturing methods, strict quality control, and timely delivery, Al Summan Metals ensures that every product offers dependable performance, an extended service life, and unmatched value for industries across the UAE and worldwide.
| Grade | Carbon Steel |
|---|---|
| Carbon Steel Square bar size | 4 to 100mm |
| CS Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Low Carbon Steel Hex Bar size | 2-100mm A/F |
| Carbon Steel Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| CS Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Low Carbon Steel Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Carbon Steel Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| CS Section | 3.0 to 12.0mm thickness |
| Low Carbon Steel Round bar size | Diameter: 3-~800mm |
| Carbon Steel Billet Size | 1/2″ to 495mm Diameter |
| CS Round Bar Standard Dimensions | Diameter / Height: Carbon Steel Rod and Bar Sizes : 0.5 inches / 0.625 inches / 0.75 inches / 0.875 inches / 1.0 inches / 1.125 inches / 1.25 inches / 1.375 inches / 1.5 inches / 1.75 inches / 2.0 inches / 2.25 inches / 2.5 inches / 2.75 inches / 3.0 inches / 3.25 inches / 3.5 inches / 3.75 inches / 4.0 inches / 4.25 inches / 4.5 inches / 5.0 inches / 5.25 inches / 5.5 inches / 6.0 inches / 7.0 inches / 8.0 inches / 9.0 inches. |
| Carbon Steel Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| CS Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Low Carbon Steel Technique | Carbon Steel Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Carbon Steel Condition | Hardened & tempered, annealed |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Form | Carbon Steel Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square Bar, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Processing | Bar cutting to 650mm |
| Our Carbon Steel Round bar conforms to NACE MR0175/ISO 15156 | |
| Carbon Steel Grades | C | Mn | Si | S Max. | P Max. |
|---|---|---|---|---|---|
| Ck 45 | 0.42/0.50 | 0.50/0.80 | 0.15/0.35 | 0.04 | 0.04 |
| Ck 55 | 0.52/0.60 | 0.60/0.90 | 0.15/0.35 | 0.04 | 0.04 |
| Ck 60 | 0.57/0.65 | 0.60/0.90 | 0.15/0.35 | 0.04 | 0.04 |
| SAE1006 | 0.08 max | 0.25/0.40 | 0.10/0.30 | 0.05 | 0.04 |
| SAE1008 | 0.10 max | 0.30/0.50 | 0.10/0.30 | 0.05 | 0.04 |
| SAE1010 | 0.08/0.13 | 0.30/0.60 | 0.10/0.30 | 0.05 | 0.04 |
| SAE1018 | 0.15/0.20 | 0.60/0.90 | 0.10/0.30 | 0.05 | 0.04 |
| SAE1020 | 0.18/0.23 | 0.30/0.60 | 0.10/0.30 | 0.09 | 0.04 |
| SAE1030 | 0.28/0.34 | 0.60/0.90 | 0.10/0.40 | 0.05 | 0.04 |
| SAE1035 | 0.32/0.38 | 0.60/0.90 | 0.10/0.40 | 0.05 | 0.04 |
| SAE1040 | 0.37/0.44 | 0.60/0.90 | 0.10/0.40 | 0.05 | 0.04 |
| SAE1045 | 0.40/0.50 | 0.60/0.90 | 0.10/0.40 | 0.05 | 0.04 |
| En-8D | 0.40/0.45 | 0.70/0.90 | 0.05/0.35 | 0.06 | 0.06 |
| En-9 | 0.50/0.60 | 0.50/0.80 | 0.05/0.35 | 0.06 | 0.06 |
| Grade | Yield Strength, | Tensile Strength, | Elongation at Break (in 50 mm) | Bulk Modulus (typical for steel) | Modulus of Elasticity | HBW | Poissons Ratio | Fatigue strength coefficient, of (Mpa) | Shear Modulus | Impacting Energy | Reduction of area, min: |
|---|---|---|---|---|---|---|---|---|---|---|---|
| a36 | 250 MPa | 400 – 550 MPa | 23.00% | 140 GPa | 200 GPa | 0.26 | 79.3 GPa | ||||
| 36300 psi | 58000 – 79800 psi | 23.00% | 20300 ksi | 29000 ksi | 0.26 | 11500 ksi | |||||
| EN45 | 35 (241) | 80 (551) | 40% | 204 Gpa | 948 | ≥63 | |||||
| EN19 | ≥930 Mpa | ≥1080 Mpa | ≥12 | 217 | ≥45 | ||||||
| 105 | 36,000 psi [250 MPa] | 70,000 psi (485 MPa] | 187 | 30% min | |||||||
| EN8 | ≥210 | ≥380 | ≥25 | ≤111HB | ≥50 |
Yes, you can order carbon steel rectangular bars and rods in bespoke dimensions and finishes. Numerous suppliers provide customization choices to fulfill particular needs for sizing and surface treatments.
Certainly, carbon steel rectangular bars are recyclable once they've been used. It's typical for them to be melted down and turned into fresh steel products, which cuts down on waste and helps preserve natural resources along the way.
Carbon steel rectangular bars and rods are available in several varieties, such as hot-rolled, cold-rolled, low carbon, medium carbon, high carbon, and heat-treated versions for structural, machining, and industrial uses.
Carbon Steel Rectangular Bars and Rods see widespread application across the automotive, machinery, construction, and general engineering industries. They work perfectly for producing fasteners, shafts, gears, structural components, and machine parts that demand both toughness and accuracy. Because of their rectangular form, they’re simple to handle and machine for fabrication, tooling, and assembly work. On top of that, these bars and rods frequently serve in frameworks, supports, and industrial equipment where strength and resistance to wear are critical. Thanks to the adaptability, affordability, and mechanical dependability of Carbon Steel Rectangular Bars and Rods, they remain a preferred option for numerous engineering and industrial uses.
Our products are supplied with mill test certificates as well as third-party test certificates, guaranteeing the highest levels of quality and compliance.
