Al Summan Metals, based in Dubai, UAE, distinguishes itself as a leading manufacturer and supplier of premium Copper Nickel Rectangular Bars. These bars are renowned for their remarkable strength, corrosion resistance, and enduring durability. Produced with careful attention to detail, they comply with international quality standards, rendering them ideal for marine, chemical, and industrial uses. Al Summan Metals is committed to preserving reliable quality through advanced manufacturing methods and stringent testing procedures. With a firm emphasis on excellence and customer satisfaction, the company supplies Copper Nickel Rectangular Bars that deliver outstanding performance, even in demanding conditions, serving a broad spectrum of engineering and fabrication requirements across numerous industries.
Copper Nickel Rectangular Bars consist mainly of copper and nickel, typically with a composition of 70-90% copper and 10-30% nickel, plus minor quantities of iron and manganese to enhance their strength and resistance to corrosion. They exhibit impressive mechanical qualities, such as high tensile strength, good flexibility, and exceptional resistance to seawater and biofouling. These bars stay stable across varying temperatures and pressures, offering great weldability and formability, which makes them well-suited for challenging environments where both mechanical performance and corrosion resistance matter.
| Standard | ASTM B111, ASME SB111 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | Mn | Cu | Pb | Fe | Ni | Zn |
|---|---|---|---|---|---|---|
| 90/10 | 1.0 max | 88.6 min | 0.5 max | 1.8 max | 9-11 max | 1 max |
| 70/30 | 1 max | 65.0 min | 0.5 max | 0.4-1.0 | 29-33 | 1 max |
| Grade | Melting point | Density | Tensilestrength | Elongation | Yieldstrength(0.2%Offset) |
|---|---|---|---|---|---|
| 90/10 | 2260°F | 8.8g/cm3 | 50000 PSi | 30% | 20000 PSi |
| 70/30 | 2260°F | 0.323 lb/in3 at 68°F | 50000 PSi | 30% | 20000 PSi |
| BD | Bright drawn | SRE | Slit rolled edge |
| CF | Cold finished | HRAP | Hot rolled annealed / pickled |
| CG | Centreless ground | HF | Hot finished |
| ST | Smooth turned | PR | Peeled / reeled |
| CD | Cold drawn | P | Polished |
| P&T | Peeled / turned | RT | Rough turned and peeled |
| Metric | US Rods | ASTM/ Canadian | Japanese | ||||
|---|---|---|---|---|---|---|---|
| Rods Size | Diam. (mm) | Rods Size | Diam. (Inch) | Rods Size | Diam. (mm2) | Rods Size | Diam. (mm) |
| 5 | 5 | #2 | 0.250 | 10M | 100 | 6 | 6 |
| 5.5 | 5.5 | #3 | 0.375 | 15M | 200 | 10 | 10 |
| 6 | 6 | #4 | 0.500 | 20M | 300 | 13 | 13 |
| 7 | 7 | #5 | 0.600 | 25M | 500 | 16 | 16 |
| 8 | 8 | #6 | 0.750 | 30M | 700 | 19 | 19 |
| 9 | 9 | #7 | 0.875 | 35M | 1000 | 22 | 22 |
| 10 | 10 | #8 | 1.000 | 45M | 1500 | 25 | 25 |
| 11 | 11 | #9 | 1.125 | 55M | 2500 | 29 | 29 |
| 12 | 12 | #10 | 1.250 | 32 | 32 | ||
| 14 | 14 | #11 | 1.375 | 35 | 35 | ||
| 16 | 16 | #12 | 1.500 | 38 | 38 | ||
| 18 | 18 | #13 | 1.600 | 41 | 41 | ||
| 20 | 20 | #14 | 1.750 | 44 | 44 | ||
| 22 | 22 | #15 | 1.875 | 48 | 48 | ||
| 25 | 25 | #16 | 2.000 | 51 | 51 | ||
| 28 | 28 | #18 | 2.250 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 | ||||||
| Grade | UNS | Werkstoff Nr. |
| 90/10 | C70600 | 2.0872 |
| 70/30 | C71500 | 2.0882 |
Yes, Copper Nickel Rectangular Bars can be tailored in size, thickness, length, and alloy composition to satisfy the particular needs of different applications. This customization guarantees peak performance in marine, chemical, and industrial settings.
In marine engineering, Copper Nickel Rectangular Bars are widely employed in shipbuilding, desalination plants, and offshore structures owing to their outstanding resistance to seawater corrosion. They also serve a crucial function in heat exchangers, condensers, and piping systems within chemical and power plants. Additionally, these bars are indispensable in the oil and gas industries, hydraulic systems, and the manufacturing of industrial machinery. Their distinctive blend of durability, thermal stability, and resistance to oxidation makes them ideal for settings where reliability and an extended service life are essential.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
