Al Summan Metals, a well-regarded manufacturer and supplier based in Dubai, UAE, has earned a strong reputation for producing top-quality Duplex Steel Bright Bars that comply with international standards. With the help of advanced technology and stringent quality control practices, Al Summan Metals ensures that each bar delivers outstanding strength, durability, and corrosion resistance. The company caters to a wide range of industries, such as oil and gas, chemical processing, construction, and marine applications. Their Duplex Steel Bright Bars are available in various dimensions and finishes, offering clients tailored solutions for challenging environments where reliability and performance are essential.
These Duplex Steel Bright Bars consist mainly of chromium (21–23%), nickel (4.5–6.5%), molybdenum (2.5–3.5%), and nitrogen, producing an excellent equilibrium between austenitic and ferritic phases. This distinctive makeup provides them with exceptional mechanical strength, elevated yield and tensile strength, and impressive resistance to pitting and stress corrosion cracking. Featuring a tensile strength of roughly 620 MPa and a yield strength of nearly 450 MPa, these bars are engineered to endure high-pressure and high-temperature environments. Their well-balanced microstructure not only boosts toughness but also preserves formability throughout machining and fabrication.
Standards : EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 10 mm To 100 mm Dia in
Length : 100 mm TO 6000 mm Length.
Specifications : ASTM A276, A479 / ASME SA276, SA479
Form :Bright
Finish :Bright, Polish & Black
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
S31803 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 22.0 – 23.0 | 3.0 – 3.5 | 4.50 – 6.50 | 0.14 – 0.20 | 63.72 min |
S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| S31803 / S32205 | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
Yes, Duplex Steel Bright Bars work well for natural gas uses thanks to their outstanding resistance to corrosion, superior strength, and long-lasting performance, which makes them perfect for pipelines and gas processing systems.
Yes, Duplex Steel Bright Bars are well-suited for hygienic and sanitary uses because of their resistance to corrosion, ease of cleaning, and capacity to endure demanding conditions, which makes them perfect for the food and pharmaceutical sectors.
Duplex Steel Bright Bars find widespread use across industries that demand both high strength and resistance to corrosion. They serve a crucial function in offshore and marine engineering, desalination facilities, chemical processing plants, and oil and gas exploration. Within construction, they are preferred for structural supports, shafts, and reinforcement thanks to their remarkable load-bearing capabilities. Moreover, the power generation as well as the pulp and paper sectors depend on these bars for their capacity to endure corrosive conditions. The blend of mechanical strength and corrosion resistance establishes Duplex Steel Bright Bars as a leading option for demanding industrial uses.
We supply products accompanied by mill test certificates as well as third-party test certificates, guaranteeing the highest standards of quality and compliance.
