Al Summan Metals, headquartered in Dubai, UAE, distinguishes itself as a leading manufacturer and supplier of premium metal products, placing special emphasis on Hastelloy B2 Forgings. Owing to their advanced manufacturing techniques and steadfast dedication to quality, Al Summan Metals delivers high-performance forgings engineered to withstand even the most corrosive settings. Recognized for their exceptional resistance to hydrochloric acid and severe chemical conditions, Hastelloy B2 Forgings serve as a preferred option across numerous industries. The company takes pride in precision engineering, longevity, and compliance with global quality benchmarks, enabling it to serve a range of sectors, such as chemical processing, pharmaceuticals, marine, and petrochemicals, within UAE and elsewhere.
Hastelloy B2 Forgings consist chiefly of nickel and molybdenum, together with small quantities of iron, cobalt, chromium, and additional elements. This distinctive composition provides them with exceptional resistance to hydrochloric acid and other strong reducing agents. The alloy delivers remarkable mechanical strength, featuring a yield strength of roughly 310 MPa and a tensile strength approaching 690 MPa. Even under severe chemical conditions, it maintains superb ductility and toughness. The fine-grained microstructure of Hastelloy B2 provides good formability, thermal stability, and resistance to stress corrosion cracking, which makes it ideal for demanding industrial forging applications.
| Standard | ASTM B564, ASME SB564 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| Hastelloy B2 | 0.02 max | 1.0 max | 0.1 max | 0.03 max | 1.0 max | Bal | 1.0 max | 2.0 max | 26 – 30 | 0.04 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 9.2 g/cm3 | 1370 °C (2500 ºF ) | Psi – 1,10,000, MPa – 760 | Psi – 51000, MPa – 350 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Hastelloy B2 | 2.4617 | N10665 |
To find out whether Hastelloy B2 forgings suit your requirements, assess how well they resist corrosion in harsh chemical settings along with their mechanical characteristics at the working temperature. Carry out procedures like tensile, impact, and corrosion resistance testing to confirm this.
Hastelloy B2's forging procedure generally requires several hours, varying with how intricate the part is and the dimensions of the material. The process covers heating, shaping, cooling, along with any required post-forging treatments.
The forging of Hastelloy B2 is best carried out at temperatures from 2,100°F to 2,300°F (1,149°C to 1,260°C). Staying within this window promotes proper material flow while preventing excessive grain growth.
These Hastelloy B2 Forgings are widely applied in industries that demand high resistance to chemical corrosion. They are especially well-suited for chemical reactors, heat exchangers, pressure vessels, and piping systems in the chemical processing and pharmaceutical fields. The alloy performs exceptionally well in settings involving hydrochloric, sulfuric, acetic, and phosphoric acids. It is also used in marine and pollution control equipment. Thanks to their outstanding mechanical strength and corrosion resistance, Hastelloy B2 Forgings deliver dependability, durability, and minimal maintenance in tough chemical and industrial applications.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
