Al Summan Metals, a leading manufacturer and supplier based in Dubai, UAE, specializes in producing high-quality Hastelloy C22 Forgings engineered to withstand corrosion and deliver strong performance at elevated temperatures. These forgings are purpose-built to endure demanding chemical settings, covering both oxidizing and reducing agents, which makes them ideal for sectors such as chemical processing, marine, and petrochemicals. Al Summan Metals takes pride in its precise manufacturing, guaranteeing dimensional accuracy and rigorous adherence to international standards, yielding Hastelloy C22 Forgings that provide exceptional strength, durability, and reliability for essential industrial and engineering applications.
Hastelloy C22 Forgings consist primarily of nickel, chromium, and molybdenum, along with modest quantities of tungsten, iron, and cobalt. This distinctive combination of alloys provides them with outstanding resistance to pitting, crevice corrosion, and stress-corrosion cracking, even in extremely aggressive environments. From a mechanical standpoint, these forgings offer a tensile strength of roughly 690 MPa and a yield strength of about 275 MPa, together with remarkable ductility, toughness, and thermal stability. Their carefully balanced alloy composition ensures reliable performance, even under severe chemical and thermal conditions.
SpecificationsASTM B564 / ASME SB564
Flat bar blocksup to 27″ width and 15,000 lbs.
Cylinders and sleevesup to 50″ maximum O.D. and 65″ maximum length
Discs and hubsup to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged ringsup to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shaftsup to 144″ maximum length and 20,000 lbs.
GradesHastelloy C22 Forging UNS (N06022), DIN (2.4602)
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
| Hastelloy C22 | Balance | 0.010 max | 12.5-14.5 | 0.50 max | 0.08 max | 2-6 | 0.02 max | 0.02 max | 2.5 max | 20-22.5 | 2.5-3.5 | 0.35 max |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000, MPa – 690 | Psi – 45000, MPa – 310 | 45 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS |
| Hastelloy C22 | N06022 | 2.4602 | – | NiCr21Mo14W | NW 6022 |
Yes, Hastelloy C22 can be shaped through forging into bespoke forms, since it offers strong formability and durability at high temperatures. That said, careful management during forging is needed to preserve its characteristics.
The ideal temperature window for forging Hastelloy C22 falls between 2,100°F (1,150°C) and 2,300°F (1,260°C). Working within this range delivers the best formability while reducing the chance of harming the material's properties.
The forging of Hastelloy C22 usually requires anywhere from a few minutes to several hours, based on the part's size and how intricate it is. The cycles of heating and cooling also affect how much total time forging demands.
These Hastelloy C22 Forgings are used in industries that demand exceptional corrosion resistance and strength. They work well for producing heat exchangers, reactors, piping systems, valves, pumps, and chemical processing equipment. On top of that, they serve in marine and offshore components, pollution control systems, and pharmaceutical machinery, owing to their capacity to endure powerful oxidizing and reducing acids. Offering great machinability, weldability, and lasting durability, Hastelloy C22 Forgings provide dependable performance in some of the harshest industrial settings.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
