Al Summan Metals, a premier manufacturer and supplier based in Dubai, UAE, has earned a strong reputation for producing high-quality **Incoloy 800 Forgings** designed for demanding industrial applications. These forgings deliver exceptional strength, corrosion resistance, and thermal stability, making them ideal for settings that face high temperatures and harsh chemicals. Al Summan Metals employs advanced forging methods together with rigorous quality control practices to ensure precision, reliability, and durability. Serving industries such as chemical processing, power generation, petrochemical, and aerospace, the company supplies Incoloy 800 forgings that deliver superior operational efficiency, longevity, and safety, all while meeting international performance and quality standards.
**Incoloy 800 Forgings** are composed primarily of nickel (30–35%), iron (making up the balance), and chromium (19–23%), together with small quantities of copper, titanium, and aluminum. This distinctive alloy makeup provides outstanding resistance to oxidation, carburization, and scaling under high-temperature conditions. From a mechanical standpoint, Incoloy 800 forgings deliver strong tensile and yield strength, favorable ductility, and exceptional thermal stability. Such properties make them well-suited for parts subjected to heavy stress, elevated temperatures, and corrosive environments, guaranteeing dependable performance over the long term.
SpecificationsASTM B564 / ASME SB564, AMS 5766
Flat bar blocksup to 27″ in width and 15,000 lbs.
Cylinders and sleevesup to 50″ maximum O.D. and 65″ maximum length
Discs and hubsup to 50″ in diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged ringsup to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shaftsup to 144″ maximum length and 20,000 lbs.
| Grade | Ni | Fe | Cr | Cu | Ti | Al | C | Mn | S | Si |
| Alloy 800 | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .15-.60 | .15-.60 | .1 max | 1.5 max | .015 max | 1.0 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | Psi – 30,000 , MPa – 205 | 30 – 35 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 800 | N08800 | 1.4876 | Z8NC32-21 | X10NiCrAlTi32-20 | NCF 800 | NA 15 | ЭИ670 | XH32T |
Yes, Incoloy 800 is able to be forged into custom shapes. Its outstanding strength and resistance to high temperatures make it well-suited for a range of forging processes.
Forging Incoloy 800 works best within a temperature window of 1,800°F to 2,200°F (982°C to 1,204°C). Staying in this range delivers the best ductility and workability throughout the forging operation.
To determine the forging strength of Incoloy 800 for aerospace uses, examine its tensile strength, yield strength, and fatigue resistance at high temperatures. Also, review how it behaves under cyclic loading and its long-term thermal stability.
**Incoloy 800 Forgings** are widely applied in industries that require materials with outstanding resistance to heat and corrosion. They are frequently employed in chemical and petrochemical plants for reactor vessels, heat exchangers, piping, and furnace components. Within the power generation sector, they appear in turbine parts, boilers, and condensers. Their mechanical strength, thermal stability, and corrosion resistance also make them well suited for aerospace and marine uses. Incoloy 800 forgings provide durable performance, safety, and reliability in high-temperature and corrosive industrial environments.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
