Al Summan Metals, a leading manufacturer and supplier based in Dubai, UAE, focuses on premium Incoloy 825 Forgings engineered to deliver exceptional performance in corrosive and high-temperature environments. These forgings are renowned for their outstanding resistance to acids, oxidation, and stress-corrosion cracking, which makes them ideal for demanding industrial uses. Al Summan Metals is dedicated to precision manufacturing, guaranteeing dimensional accuracy and rigorous compliance with international standards, producing Incoloy 825 Forgings that offer superior strength, durability, and reliability. These forgings are commonly used across the chemical, marine, and oil & gas industries, where durability and corrosion resistance are truly essential.
Incoloy 825 Forgings consist of 38–46% nickel, 19.5–23.5% chromium, 2.5–3.5% molybdenum, 1.5–3% copper, together with small quantities of titanium and iron. This distinctive combination provides them with outstanding resistance to reducing as well as oxidizing acids, including sulfuric and phosphoric acid. From a mechanical standpoint, they demonstrate a tensile strength of around 550 MPa and a yield strength of about 220 MPa, combined with high ductility and impact strength. Their carefully balanced composition ensures remarkable stability and toughness, even under severe thermal and chemical conditions.
SpecificationsASTM B564 / ASME SB564
Flat bar blocksup to 27″ wide and 15,000 lbs.
Cylinders and sleevesup to 50″ maximum outside diameter and 65″ maximum length
Discs and hubsup to 50″ in diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged ringsup to 84″ maximum outside diameter and 40″ maximum length
Rounds, shafts and step shaftsup to 144″ maximum length and 20,000 lbs.
| Grade | C | Mn | Si | S | Al | Ti | Fe | Ni | Cr |
| Incoloy 825 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | 0.40 max | 0.40 max | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa -930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Alloy 825 | N08825 | 2.4858 | NC22DNB4M | NiCr22Mo9Nb | NCF 825 | NA 21 | ЭП703 | ЭИ602 |
To assess whether Incoloy 825 Forgings suit your needs, evaluate what your application demands in terms of corrosion resistance, strength, and temperature tolerance. Refer to product specifications and industry standards to confirm compatibility with your operational environment.
The forging procedure for Incoloy 825 generally requires anywhere from several hours to days, based on the dimensions, intricacy, and particular needs of the part. Extra time might be required for heat treatment and quality checks.
Yes, Incoloy 825 can be shaped into custom forms thanks to its outstanding workability and adaptability. Expert forging methods and accurate tooling guarantee it satisfies particular design and application needs.
Incoloy 825 Forgings are used across industries that operate in highly corrosive settings. They’re ideal for producing parts in chemical processing plants, pollution control systems, marine equipment, oil and gas extraction, and heat exchangers. Because they resist chloride-induced corrosion and oxidation, they work exceptionally well for flue gas scrubbers, tanks, piping systems, and evaporators. Offering great weldability, strength, and lasting stability, Incoloy 825 Forgings provide dependable performance in demanding conditions, making them a preferred option for critical industrial applications.
We supply materials accompanied by mill test certificates as well as third-party test certificates, guaranteeing top-tier quality and full compliance.
