Al Summan Metals, based in Dubai, UAE, has built a strong reputation as a trustworthy manufacturer and supplier of premium **Inconel 625 Forgings**. Well known for their precision, durability, and dedication to international standards, Al Summan Metals focuses on producing nickel-based alloy forgings that perform exceptionally in extreme conditions. Inconel 625, a nickel-chromium-molybdenum alloy, is highly valued for its outstanding resistance to oxidation, corrosion, and high-temperature creep, making it an ideal choice for applications across the aerospace, marine, chemical, and power generation sectors. Through advanced forging methods and stringent quality control, Al Summan Metals ensures that its Inconel 625 Forgings provide reliable, long-lasting, and high-performance solutions even for the most challenging industrial environments.
Composed mainly of nickel (a minimum of 58%), these Inconel 625 Forgings also contain chromium (20–23%), molybdenum (8–10%), and small quantities of iron, niobium, and additional elements. This distinctive makeup gives them remarkable mechanical strength, superb resistance to numerous acids, and excellent defense against pitting, crevice corrosion, and high-temperature oxidation. Regarding their mechanical characteristics, these forgings offer a tensile strength between 827 and 1,034 MPa, a yield strength from 414 to 517 MPa, and notable elongation, which makes them ideal for high-stress and extreme temperature uses.
SpecificationsASTM B564 / ASME SB564, AMS 5666
Flat bar blocksup to 27″ width and 15,000 lbs.
Cylinders and sleevesup to 50″ maximum O.D. and 65″ maximum length
Discs and hubsup to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged ringsup to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shaftsup to 144″ maximum length and 20,000 lbs.
| Grade | C | Mn | Si | S | Al | Ti | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | 0.40 max | 0.40 max | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa -930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Alloy 625 | N06625 | 2.4856 | NC22DNB4M | NiCr22Mo9Nb | NCF 625 | NA 21 | ХН75МБТЮ | ЭИ602 |
Temperature regulation while forging Inconel 625 secures ideal material characteristics, avoiding brittleness and preserving both its strength and ductility. Effective temperature control additionally boosts consistency, cutting down on defects and raising the overall quality.
Inconel 625 Forgings carry a high price tag because of the elevated cost of raw materials and intricate production methods. On top of that, machining them can prove difficult at particular temperatures, calling for dedicated equipment and methods.
To find out whether Inconel 625 Forgings suit your requirements, match their material characteristics against what your application demands and talk to suppliers about customized options.
Inconel 625 Forgings are widely applied across industries that require resistance to corrosion, oxidation, and elevated temperatures. They are ideally suited for aerospace parts, marine hardware, chemical processing equipment, heat exchangers, turbines, valves, and piping systems. Additionally, they serve an essential function in the power generation, oil and gas, and petrochemical sectors, where durability, strength, and endurance against severe environmental conditions are essential. Owing to their outstanding mechanical properties, corrosion resistance, and high-temperature capability, Inconel 625 Forgings are the preferred selection for demanding engineering and industrial applications.
We deliver products supplied with mill test certificates as well as third-party test certificates, guaranteeing the highest standards of quality and compliance.
