Al Summan Metals distinguishes itself as a premier manufacturer and supplier of Inconel 686 Bars and Rods, proudly located in Dubai, UAE. They focus on delivering high-quality nickel-chromium-iron-molybdenum alloy solutions customized for demanding industrial applications. The company puts a strong emphasis on precision manufacturing, stringent quality control, and compliance with international standards, guaranteeing that their materials offer outstanding performance, durability, and corrosion resistance. Inconel 686 Bars and Rods are especially valued for their impressive high-temperature strength, oxidation resistance, and superior corrosion resistance, making them ideal for harsh environments. With a commitment to on-time delivery, competitive pricing, and reliable customer support, Al Summan Metals serves the aerospace, chemical processing, marine, and power generation sectors with their high-performance superalloy products.
The Inconel 686 Bars and Rods are made up mainly of nickel, chromium, iron, and molybdenum, which combine to deliver exceptional corrosion resistance and mechanical strength. These bars are recognized for their superb tensile strength, resistance to creep, and durability even under high temperatures, as well as impressive resistance to pitting, stress-corrosion cracking, and oxidation. Inconel 686 keeps its dimensional stability and mechanical integrity even in severe chemical and thermal environments. This alloy can undergo heat treatment to enhance its hardness and toughness while retaining its ductility. Its distinctive composition ensures dependable performance, enduring durability, and fitness for critical applications where both mechanical strength and corrosion resistance are essential.
| Element | Content (%) |
|---|---|
| Nickel, Ni | 59 |
| Chromium, Cr | 19-23 |
| Molybdenum, Mo | 15-17 |
| Iron, Fe | ≤ 5 |
| Tungsten, W | 3.0-4.40 |
| Manganese, Mn | ≤ 0.75 |
| Phosphorous, P | ≤ 0.040 |
| Sulfur, S | ≤ 0.020 |
| Titanium, Ti | 0.020-0.25 |
| Carbon, C | ≤ 0.010 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 721.9 MPa | 104700 psi |
| Yield strength (@strain 0.200%) | 364 MPa | 52800 psi |
| Elastic modulus | 207 GPa | 30000 ksi |
| Shear modulus | 77 GPa | 11200 ksi |
| Poisson’s ratio | 0.34 | 0.34 |
| Elongation at break | 71% | 71% |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 721.9 MPa | 104700 psi |
| Yield strength (@strain 0.200%) | 364 MPa | 52800 psi |
| Elastic modulus | 207 GPa | 30000 ksi |
| Shear modulus | 77 GPa | 11200 ksi |
| Poisson’s ratio | 0.34 | 0.34 |
| Elongation at break | 71% | 71% |
| Properties | Metric | Imperial |
|---|---|---|
| Thermal expansion co-efficient (@21-100°C/69.8-212°F) | 11.97 µm/m°C | 6.650 µin/in°F |
Yes, Inconel 686 Bars/Rods are engineered to deliver outstanding performance in high-temperature settings reaching up to 980°C.
Yes, Inconel 686 bars/rods can be welded with conventional methods, though preheating and dedicated filler materials are advised to achieve robust, corrosion-resistant welds.
Yes, we supply bars and rods in both standard and customized sizes and finishes to suit your particular project needs. For further information, email us at sales@alsummanmetals.ae
Inconel 686 Bars and Rods are widely applied across industries that require materials able to withstand extreme temperatures, corrosive settings, and heavy mechanical stress. They are commonly used in chemical processing facilities for heat exchangers, reactor vessels, piping systems, and valves, owing to their outstanding resistance to acids and oxidizing agents. In marine settings, Inconel 686 serves in seawater handling equipment, pumps, and fasteners, demonstrating its adaptability and dependability under demanding conditions.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
