Al Summan Metals, a leading manufacturer and supplier based in Dubai, UAE, specializes in producing high-quality **Monel Flat Bars** built for demanding industrial and marine applications. Known for their outstanding corrosion resistance, strength, and durability, these flat bars are ideal for harsh conditions, including chemical processing, seawater exposure, and high-temperature scenarios. Al Summan Metals uses advanced manufacturing methods and strict quality control to ensure accurate dimensions, uniform mechanical properties, and enduring performance. Serving industries such as chemical, marine, aerospace, and power generation, the company delivers Monel flat bars that provide superior reliability, operational efficiency, and long service life in critical applications.
**Monel Flat Bars** are composed primarily of nickel (roughly 63%) and copper (28–34%), together with small quantities of iron, manganese, and additional elements. This distinctive makeup gives them exceptional resistance to corrosion, particularly when exposed to acids, alkalis, and seawater. From a mechanical standpoint, Monel flat bars display high tensile and yield strength, superb toughness, and solid ductility. Such properties make them well suited for uses that require dimensional stability, longevity, and reliable performance under harsh chemical and marine environments.
Dimensions :ASTM, ASME, API.
Length :2 meters – 7 meters ( 8 feet to 24 feet)
Size Range :38×10 mm to 150×25 mm
Finish :Bright, Black, Polished finish
Form :Flat Bar
Condition :Cold Drawn & Polished Cold Drawn, Centreless Ground & Polished
Other Services :CNC Machining, Centreless Grinding (CG), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Minor Fabrication
Flat Bars End Finish :Sheared / Bandsaw Cut / Hot-Cut With Grinding / Water Jet Cutting.
| Element | Max | Min |
| Ni | – | 63.0 |
| Fe | 1.0 – 2.5 | – |
| C | 0.3 | – |
| Mn | 2.0 | – |
| Si | 0.5 | – |
| Cu | 28.0 – 34.0 | – |
| Al | 0.50 | – |
| S | 0.02 | – |
| Element | Monel |
| Density | 8.8 g/cm3 |
| Melting Point | 1350 °C (2460 °F) |
| Tensile Strength | Psi – 80,000 , MPa – 550 |
| Yield Strength (0.2%Offset) | Psi – 35,000 , MPa – 240 |
| Elongation | 40 % |
Yes, we supply bars and rods in both standard and customized sizes and finishes to suit your particular project needs. For more information, email us at sales@alsummanmetals.ae
Yes, Monel Flat Bars provide outstanding resistance to seawater corrosion, which makes them well-suited for marine uses such as shipbuilding, offshore platforms, and seawater equipment.
Yes, Monel Flat Bars offer strong resistance to a wide range of acidic environments, which makes them well-suited for chemical processing, reactors, and other industries where contact with acids is frequent.
**Monel Flat Bars** are widely used across industries that demand materials offering outstanding corrosion resistance and mechanical strength. They are frequently applied in marine hardware, fasteners, pump shafts, and valve components exposed to seawater. Within the chemical and petrochemical sectors, they play a vital role in reactor components, piping systems, and heat exchangers. Thanks to their remarkable mechanical properties, longevity, and resistance to corrosion, they are also well suited for aerospace, power generation, and heavy industrial uses. Monel flat bars provide lasting reliability, efficiency, and high-performance operation in tough and demanding conditions.
We supply materials accompanied by mill test certificates as well as third-party test certificates, guaranteeing top-tier quality and compliance.
