Al Summan Metals, a premier manufacturer and supplier based in Dubai, UAE, is dedicated to producing high-quality **Monel Hex Bars** that are ideal for demanding industrial and marine applications. These hex bars are renowned for their exceptional corrosion resistance, remarkable mechanical strength, and durability, making them dependable performers even in the most severe environments, such as acidic, alkaline, and seawater conditions. Al Summan Metals employs advanced manufacturing methods and stringent quality control to ensure accurate dimensions, uniform mechanical performance, and lasting reliability. Serving industries like chemical processing, marine engineering, aerospace, and power generation, the company provides Monel hex bars that deliver superior performance, operational efficiency, and longevity for critical applications.
Composed mainly of nickel (roughly 63%) and copper (28–34%), with minor quantities of iron, manganese, and other trace elements, **Monel Hex Bars** owe their properties to this distinctive alloy blend, which grants them exceptional corrosion resistance, particularly in seawater and chemically harsh conditions. From a mechanical standpoint, Monel hex bars deliver high tensile and yield strength, outstanding toughness, and solid ductility. Thanks to these traits, they are perfectly suited for uses that require dependable performance, dimensional stability, and lasting durability in demanding industrial and marine environments.
Dimensions :ASTM, ASME, API.
Length :2 meters – 7 meters ( 8 feet to 24 feet)
Size Range :38×10 mm to 150×25 mm
Finish :Bright, Black, Polished
Form :Hexagonal Bar
Condition :Cold Drawn & Polished Cold Drawn, Centreless Ground & Polished
Other Services :CNC Machining, Centreless Grinding (CG), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Minor Fabrication
Flat Bars End Finish :Sheared / Bandsaw Cut / Hot-Cut With Grinding / Water Jet Cutting.
| Element | Max | Min |
| Ni | – | 63.0 |
| Fe | 1.0 – 2.5 | – |
| C | 0.3 | – |
| Mn | 2.0 | – |
| Si | 0.5 | – |
| Cu | 28.0 – 34.0 | – |
| Al | 0.50 | – |
| S | 0.02 | – |
| Tensile strength, Ultimate | 550 Mpa |
| Tensile strength, Yield | 240 Mpa |
| Elongation at Break | 48% |
Yes, we supply bars and rods in both standard and custom sizes and finishes to suit the particular needs of your project. To learn more, email us at sales@alsummanmetals.ae
Monel Hex Bars can be machined but call for specialized tools and methods because of their hardness. Careful handling guarantees precision for critical applications across various industries.
Yes, Monel Hex Bars retain their durability and resistance to oxidation even under high temperatures, which makes them well-suited for use in high-temperature settings such as aerospace and chemical processing.
**Monel Hex Bars** are extensively used across industries requiring strong corrosion resistance and mechanical strength in hexagonal bar forms. They are commonly seen in marine hardware, fasteners, pump shafts, and valve parts that make contact with seawater. Within the chemical and petrochemical fields, Monel hex bars play a vital role in piping systems, reactor parts, and heat exchangers. Their excellent combination of mechanical properties, corrosion resistance, and durability also makes them well suited for aerospace, power generation, and other demanding industrial applications. Monel hex bars deliver long-term reliability, efficiency, and performance under challenging conditions.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
