Al Summan Metals, a highly regarded manufacturer and supplier based in Dubai, UAE, focuses on premium-grade Nickel Alloy 200 Bars and Rods. Crafted from commercially pure nickel, these products offer outstanding resistance to alkalis, acids, and demanding environments. Thanks to their superb thermal and electrical conductivity, Nickel Alloy 200 Bars and Rods are ideally suited for a wide range of industrial and engineering uses. Al Summan Metals is dedicated to guaranteeing that every product complies with international quality standards, delivering remarkable strength, precision, and performance for applications in chemical processing, marine, and electrical industries where reliability and durability are essential.
Nickel Alloy 200 Bars and Rods are composed of more than 99% pure nickel, together with small quantities of iron, copper, manganese, silicon, and carbon. This distinctive makeup gives rise to exceptional mechanical properties and resistance to corrosion, particularly in caustic and neutral salt settings. The alloy features a tensile strength of roughly 370 MPa and a yield strength of 105 MPa, as well as remarkable ductility and toughness. It further preserves its stability and mechanical integrity over a broad temperature range, guaranteeing dependable performance even under challenging conditions.
| Standard | ASTM B160, ASME SB160 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 2000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | UNS | WNR. | JIS | EN |
|---|---|---|---|---|
| Nickel 200 | N02200 | 2.4066 | NW 2200 | Ni 99.2 |
Yes, Nickel Alloy 200 Bars provide outstanding resistance to corrosion, particularly in alkaline settings and against numerous industrial chemicals. They show strong resistance to corrosion across a range of aqueous environments.
Nickel Alloy 200 Rods can indeed be tailored in a range of sizes and lengths to satisfy particular specifications. These customization choices provide the flexibility needed to comply with industry standards and suit application demands.
Nickel Alloy 200 Bars and Rods deliver solid performance at moderate temperatures but offer limited strength when exposed to high temperatures.
Nickel Alloy 200 Bars and Rods are widely applied across industries requiring materials that resist corrosion, withstand heat, and conduct electricity. They work well for manufacturing chemical processing equipment, heat exchangers, marine parts, and caustic evaporators. Beyond that, these rods serve the food processing, aerospace, and electrical fields thanks to their outstanding formability and non-magnetic characteristics. Because of their exceptional strength and ability to withstand reducing chemicals, they are well suited for use with caustic soda, acids, and alkalis. Offering a lengthy service life, Nickel Alloy 200 Bars and Rods stand as a reliable option for demanding industrial uses.
We supply materials accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest levels of quality and compliance.
