Al Summan Metals, a premier manufacturer and supplier based in Dubai, UAE, is renowned for its high-quality Nickel Alloy 200 Forgings. Made from commercially pure nickel, these forgings are engineered to easily resist corrosion, oxidation, and demanding environments. They offer remarkable mechanical strength, thermal conductivity, and toughness, which makes them ideal for the chemical and marine industries. Al Summan Metals prides itself on ensuring that every forging is carefully produced to satisfy international standards, delivering products that guarantee reliability, durability, and exceptional performance even in the most challenging industrial conditions.
Nickel Alloy 200 Forgings are made up of more than 99% pure nickel, along with minor additions of copper, iron, manganese, carbon, and silicon. This unique composition provides them with outstanding resistance to alkaline and neutral salt solutions, all while preserving their ductility and thermal stability. From a mechanical standpoint, they offer a tensile strength of roughly 370 MPa and a yield strength of 105 MPa, together with superb elongation and toughness. These properties make Nickel Alloy 200 Forgings well-suited for both high-temperature and cryogenic uses.
| Specifications | ASTM B564, ASME SB564 |
|---|---|
| Standard | BS 3072, BS 3073, BS 3074, BS 3075, BS 3076, NA11 DIN 17740, 17750, 17751, 17752, 17753, 17754, DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
After forging Nickel Alloy 200, regulated cooling techniques like air cooling or furnace cooling are generally applied to prevent sudden temperature shifts and avoid distortion. Slow cooling helps preserve the material's mechanical properties and stops cracking from occurring.
Following forging, Nickel Alloy 200 undergoes processes such as annealing to alleviate internal stresses and enhance ductility, after which machining or surface finishing is performed to reach exact dimensions and surface quality. These steps guarantee the alloy's optimal performance and structural integrity.
The forging of Nickel Alloy 200 is best carried out at temperatures from 1,900°F (1,038°C) up to 2,100°F (1,149°C). Working within these limits provides adequate malleability and supports attaining the intended mechanical properties throughout forging.
These forgings see broad use across sectors demanding strong corrosion resistance and purity. They suit chemical processing equipment, caustic evaporators, heat exchangers, and marine hardware perfectly. Beyond that, Nickel Alloy 200 Forgings are also used in food processing, aerospace, and electrical applications owing to their excellent conductivity and non-magnetic characteristics. Their outstanding resistance to reducing chemicals and acids makes them vital for building components that operate in aggressive chemical settings. With Nickel Alloy 200 Forgings, you can rely on extended service life, dependability, and efficiency, even under demanding operating conditions.
Our products are supplied with mill test certificates as well as third-party test certificates, guaranteeing the highest levels of quality and compliance.
Al Summan Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Dubai, UAE
