Al Summan Metals, a leading manufacturer and supplier based in Dubai, UAE, focuses entirely on producing high-quality **Nickel Alloy Bright Bars** that are ideal for demanding industrial and high-temperature environments. Recognized for their outstanding corrosion resistance, notable mechanical strength, and polished surface finish, these bright bars are exactly what’s required for precision components operating under extreme conditions. Al Summan Metals uses advanced manufacturing methods and strict quality control to ensure steady mechanical performance, precise dimensions, and lasting durability. They serve a range of industries, such as chemical processing, aerospace, power generation, and petrochemicals, delivering Nickel Alloy bright bars that provide dependable performance, operational efficiency, and outstanding longevity in critical applications.
**Nickel Alloy Bright Bars** are primarily composed of nickel, chromium, and iron, along with additional elements such as molybdenum, copper, and cobalt included depending on the particular grade. This distinctive composition provides exceptional resistance to oxidation, corrosion, and thermal breakdown at elevated temperatures. From a mechanical standpoint, Nickel Alloy bright bars deliver high tensile and yield strength, remarkable creep resistance, and outstanding fatigue performance. Their bright surface finish not only improves machinability but also guarantees dimensional stability, which makes them well suited for precision and high-performance applications.
| Grade | Nickel Alloy – Pure Nickel |
|---|---|
| Specification | Nickel Bar Cold Finished : B160, SB160 400: B164, SB164, QQ-N-281 405: B164, SB164, QQ-N-281, ASTM B160 |
| Standard | ASTM, ASME, API, GB, AISI, DIN, EN, SUS, UNS |
| Round bar size | Diameter: 3-~800mm |
| Round Bar Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Round Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Processing | Bar cutting to 650mm |
| Ni | Fe | C | Mn | Si | Cu | Mg | Ti | S |
|---|---|---|---|---|---|---|---|---|
| 99.0 Min | 0.4 Max | 0.02 Max | 0.35 Max | 0.2 Max | 0.25 Max | 0.15 Max | 0.1 Max | 0.01 Max |
| 99.0 Min | 0.4 Max | 0.15 Max | 0.35 Max | 0.1 Max | 0.25 Max | – | – | 0.01 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| SIZE IN INCHES | LENGTH IN INCHES | WGHT./FT. |
|---|---|---|
| .500 | 120/216 | 0.749 |
| .750 | 120/216 | 1.686 |
| .875 | 120/216 | 2.295 |
| 1.250 | 120/216 | 4.683 |
| 1.375 | 120/216 | 5.666 |
| 1.500 | 120/316 | 6.743 |
| 1.750 | 120/216 | 9.179 |
| 2.000 | 120/216 | 11.988 |
| 2.250 | 120/216 | 15.173 |
| 2.500 | 120/216 | 18.732 |
| 2.750 | 120/216 | 22.665 |
| 2.875 | 120/216 | 24.773 |
| 3.000 | 120/216 | 26.974 |
| 3.250 | 120/216 | 31.657 |
| 3.500 | 120/216 | 36.714 |
Uncover the advantages of Nickel Alloy Bright Bars, such as superior strength, resistance to corrosion, long-lasting durability, and adaptability for industrial uses.
Yes, we supply bars and rods in both standard and made-to-order sizes and finishes to suit your particular project needs. For further information, email us at sales@alsummanmetals.ae
These **Nickel Alloy Bright Bars** are broadly used across industries that require high-strength, corrosion-resistant, and heat-tolerant materials with an excellent surface finish. You’ll commonly see them in aerospace components, turbine shafts, and high-temperature structural parts. Within the chemical and petrochemical sectors, they’re vital for piping systems, reactor components, heat exchangers, and valves exposed to demanding environments. Their outstanding mechanical strength, thermal stability, and smooth finish also make them ideal for power generation, marine, and other high-performance industrial uses.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
