Al Summan Metals ranks among the most well-known manufacturers and distributors located in Dubai, UAE. This reputation stems from its high-quality metal products designed for various industrial needs. With a strong dedication to excellence and innovation, Al Summan Metals concentrates on supplying a broad range of alloys and metal solutions, among which is the widely favored Nilo Alloy 48 Bars and Rods. Recognized for its excellent thermal expansion characteristics, the Nilo Alloy 48 is the preferred material wherever precision and durability matter in demanding operating conditions. Drawing on the backing of cutting-edge technology and an experienced team, Al Summan Metals achieves peak product performance while meeting global standards and individual customer needs.
This 48% Nickel Balance Iron contains silicon within the range of (≤0.3%), (≤0.5%) manganese and (≤0.05) carbon. Among its properties Nilo Alloy 48 Bars and Rods stand out with a low coefficient of thermal expansion that resembles the level of glass or ceramic. High dimensional stability tensile strength of roughly 450 MPa, yield at 250MPa and around 30 elongation. Its thermal expansion coefficient is ~8.5 x 10⁻⁶/°C (20–300°C), which makes it suitable for hermetic seals and electronic applications. Nilo 48 is recognized for its resistance to oxidation and corrosion, preserving its mechanical integrity across a wide temperature range.
| Grade | C | Mn | P | S | Si | Ni | Cr | Fe |
| Nilo Alloy 48 | 0.05 max | 0.80 max | 0.025 max | 0.025 max | 0.030 max | 48 | 0.250 max | Bal |
| Material | Condition | Tensile Strength | Yield Strength (0.2% Offset) | Elongation (%) | ||
| psi | MPa | psi | MPa | |||
| Alloy 48 | Annealed | 71,000 | 520 | 38,000 | 250 | 43 |
| STANDARD | WERKSTOFF NR. | UNS |
| Nilo Alloy 48 | – | K94800 |
To care for Nilo Alloy 48 bars, keep them in a dry space, prevent contact with corrosive materials, use non-abrasive tools for cleaning, and check them frequently for signs of damage or corrosion.
Yes, Nilo Alloy 48 Bars and Rods can be tailored in both size and length to satisfy particular needs, making sure they are suited for a wide range of industrial and engineering uses.
Nilo Alloy 48 bars and rods perform exceptionally well in high-temperature settings thanks to their outstanding thermal expansion control, resistance to oxidation, and stability, which makes them perfectly suited for aerospace, electronic, and industrial applications.
Nilo Alloy 48 Bars and Rods see extensive use in controlled thermal expansion and offer high stability up to extreme temperatures. The lead frames and connectors in the production of electronic components rely on these rods because they form a hermetic seal with glass and ceramics. Owing to their high precision expansion, Nilo Alloy 48 is employed in aerospace instruments, telecommunication equipment, and industrial thermocouples. It also serves in medical equipment, scientific apparatus, and cryogenic systems where uniform dimensionality is highly essential. Moreover, the oxidation and corrosion resistance further enhances the reliability of this material in harsh environments, thereby supporting applications in the automotive and energy sectors.
We supply products accompanied by mill test certificates as well as third-party test certificates, guaranteeing the highest standards of quality and compliance.
