Al Summan Metals, headquartered in Dubai, UAE, has earned a strong reputation as a dependable manufacturer and supplier of premium Nimonic C263 Bars and Rods. By placing great emphasis on precision engineering and quality, Al Summan Metals delivers products that meet international standards for strength, performance, and reliability. This company’s Nimonic C263 Bars and Rods are engineered to withstand high temperatures, resist corrosion, and cope with mechanical stress, making them ideal for the most demanding industrial and aerospace uses. Owing to their cutting-edge manufacturing techniques and thorough testing, Al Summan Metals ensures dependable quality, longevity, and customer satisfaction throughout their complete product lineup.
Nimonic C263 Bars and Rods are manufactured from a nickel-cobalt-chromium-molybdenum alloy, containing roughly 52% nickel, 20% chromium, 20% cobalt, 6% molybdenum, plus small quantities of titanium and aluminum. They offer excellent mechanical properties, delivering a tensile strength of 1000 to 1200 MPa and a yield strength between 750 and 900 MPa, together with outstanding creep and oxidation resistance up to 800°C. These qualities make Nimonic C263 the preferred option for high-temperature and high-stress applications requiring superior mechanical stability and corrosion resistance.
Dimension : EN, DIN, JIS, ASTM, BS, ASME, AISI
Grade : Nimonic C263 Round Bars
Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Form : Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc.
Surface : Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline
Application : Chemical process, Food processing, Petrochemical, Pollution control, Pulp and Paper, Refining
Condition : Cold Drawnd Pulished Cold Drawn Centreless Ground & Polished.
Our Nimonic Alloy C263 Round Bars comply with NACE MR0175/ISO 15156
| Nimonic Alloy 263 | 0.04-0.08 | 19 – 21 | 19 – 21 | 1.90 – 2.40 | 0.60 max | 0.40 max | 0.20 max | 0.60 max |
| Tensile strength | ISO 6892-1:2009(B) Annex D | 900 ± 40 MPa | 1100 ± 30 MPa |
| Yield strength (Rp 0.2 %) | ISO 6892-1:2009(B) Annex D | 650 ± 40 MPa | 800 ± 30 MPa |
| Elongation at break | ISO 6892-1:2009(B) Annex D | 40 ± 5 % | 35 ± 5 % |
| Young’s Modulus | – | 220 ± 15 MPa | 220 ± 15 MPa |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Nimonic Alloy 263 | 2.4650 | N07263 |
Nimonic C263 rods are typically manufactured in diameters between 3mm and 200mm, with commonly requested sizes such as 6mm, 12mm, 25mm, 50mm, and 100mm. Custom dimensions can also be provided on request.
Nimonic C263 rods come in diameters spanning from 3mm up to 250mm. Typical finishes are hot-rolled, cold-drawn, and polished, providing flexibility for a wide range of applications.
Nimonic C263 bar is indeed weldable. For the best outcome, it is generally joined by gas tungsten arc welding (GTAW) or gas metal arc welding (GMAW) using a compatible filler material.
Nimonic C263 Bars and Rods are commonly employed across the aerospace, power generation, and chemical processing sectors. They are especially well-suited for producing gas turbine parts, combustion chambers, transition ducts, and exhaust systems that demand both strength and resistance to oxidation at high temperatures. On top of this, they serve a vital function in heat exchangers, fasteners, and pressure vessels running in corrosive and high-temperature environments. Their remarkable fabricability and weldability make them perfect for essential engineering applications where reliability, durability, and performance cannot be compromised. Nimonic C263 Bars and Rods stand as the top pick for industries that require outstanding thermal and mechanical performance.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
