Al Summan Metals, based in Dubai, UAE, distinguishes itself as a leading manufacturer and supplier of high-quality Stainless Steel 304 Bars and Rods. Recognized for their steadfast commitment to quality, precision, and reliability, Al Summan Metals provides stainless steel products that meet international standards and serve a wide range of industrial requirements. Their Stainless Steel 304 Bars and Rods are engineered to deliver exceptional corrosion resistance, mechanical strength, and durability, making them ideal for both structural and industrial uses. With a firm focus on reliable quality, advanced manufacturing methods, and timely delivery, Al Summan Metals guarantees that their materials provide durable performance and value across a wide array of industries.
Stainless Steel 304 Bars and Rods are produced from an austenitic stainless steel grade containing 17–19% chromium, 8–12% nickel, and up to 0.08% carbon, giving them outstanding corrosion resistance and mechanical strength. Regarding mechanical properties, these bars and rods feature a tensile strength between 505 and 700 MPa, a yield strength of 215 to 275 MPa, and an elongation of roughly 40%, delivering excellent toughness, ductility, and formability. Their distinctive composition ensures stability at elevated temperatures, resistance to oxidation, and lasting durability, making them well suited for a broad range of industrial, structural, and chemical applications where strength and reliability are essential.
| Specification | ASTM A479/ SA479 ASTM A276/ ASME SA276 |
|---|---|
| Grade | Stainless Steel 304 (UNS S30400) |
| Hex Bar size | 18 to 57mm (11/16″ – 2-3/4″) |
| Round bar size | OD 4mm to 500mm |
| Square bar size | 18mm to 47mm (11/16″- 1-3/4″) |
| Billet Size | 1/2″- 495mm Dia. |
| Rectangles Size | 33 x 30mm – 295 x 1066mm |
| Bright Bar | OD 4mm to 100mm |
| Tolerance | K12 H12, K10, H9, H11, H8, H13K9, H10, K11, or as per need |
| Flat bar size | 1/2” to 10” in thickness of 2 to 150mm |
| Angle bar size | 3*20*20~12*100*100 |
| Finish | centreless ground, Cold (bright) drawn, hot rolled, peeled, smooth turned, hot rolled annealed, slit rolled edge, Bright, Rough Turned, Grinding, Polish & Black |
| Form | Flat Bar, Hollow, Round, Square, Triangle, Rectangle, Half Round Bar, Rod, T-Bar, Precision Ground Bar, Hex (A/F), Blocks, Channel Bar, Threaded, Round Rod, Billet, Profiles, I/H Bar, Ingot, Rings, Forging etc. |
| Technique | 440C Stainless Steel Hot Rolled, Cold Drawn, Rod, Forged Round Bar, Cold Rolled |
| Condition | annealed, Hardened & tempered |
| Section | 3.0 -12.0 mm thickness, 80 x 40 to 150 x 75mm section |
| Channel Bar | 5.0 – 6.0mm thickness |
| Surface | Bright, Cold Drawn, Hot Rolled Pickled, Sand Blasting Finished, Polished, Hairline |
| Hollow Bar | 32mm OD x 16mm ID – 250mm OD x 200mm ID |
| Grade | Mn | C | Si | S | P | Cr | Ni | Mo | N |
| SS 304 | 2 maximum | 0.08 maximum | 0.75 maximum | 0.030 maximum | 0.040 maximum | 18 – 20 | 8 – 11 | – | – |
| Density | Elongation | Tensile Strength | Melting Point | (0.2%Offset) Yield Strength |
| 8.0 g/cm3 | 35 % | MPa – 515 , Psi – 75000 | 1400 °C (2550 °F) | MPa – 205, Psi – 30000 |
|
Type |
SIZES (Inches) |
ISO Tolerance |
SIZES (mm) |
|---|---|---|---|
|
Peeled and Polished |
1.50″ to 6.00″ |
h11-DIN 1013 |
40.00 to 150.00 |
|
Cold Drawn and Ground |
5/6″ to 2.50″ |
h9-h8-h11-h10 |
10.00 to 75.00 |
|
Cold Drawn and Polish |
1/8″ to 3.00″ |
h9-h8-h11-h10 |
3.00 to 75.00 |
|
Peeled and Ground |
3/4″ to 2.00″ |
h10-h9-h11 |
20.00 to 50.00 |
|
STANDARD |
UNS |
WERKSTOFF NR. |
BS |
JIS |
AFNOR |
GOST |
EN |
|
SS 304 |
S30400 |
1.4301 |
304S31 |
SUS 304 |
Z7CN18‐09 |
08Х18Н10 |
X5CrNi18-10 |
Stainless Steel 304 Bars and Rods provide outstanding corrosion resistance, superior tensile strength, and solid machinability. They also resist oxidation exceptionally well and can endure diverse industrial and environmental conditions, which makes them well-suited for a broad spectrum of applications.
Stainless Steel 304 Bars and Rods find extensive use across sectors including food processing, automotive, chemical, pharmaceutical, and construction. Thanks to their long-lasting nature and resistance to corrosion, they serve to produce components such as shafts, fasteners, pipes, and structural parts.
Yes, Stainless Steel 304 Bars and Rods hold up nicely in high-temperature settings, capable of enduring temperatures as high as 870°C (1600°F) under intermittent service. This makes them well-suited for use in heat exchangers, ovens, and other high-heat environments.
Stainless Steel 304 Bars and Rods are widely applied in chemical processing, food and beverage equipment, pharmaceutical machinery, marine applications, and architectural components, owing to their outstanding corrosion resistance and mechanical performance. They are especially suitable for producing fasteners, shafts, structural supports, and machinery parts that face harsh or corrosive conditions. In addition, these bars and rods serve in heat exchangers, storage tanks, piping systems, and industrial frameworks that require strength, durability, and reliability. This combination of corrosion resistance, mechanical strength, and versatility makes 304 Bars and Rods a favored option across numerous industries.
We provide products supplied with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
