Al Summan Metals, headquartered in Dubai, UAE, is a premier manufacturer and supplier specializing in producing high-quality **Stainless Steel 304 Forgings** for a wide range of industrial and commercial applications. These forgings are renowned for their exceptional corrosion resistance, mechanical strength, and durability, making them dependable performers across diverse environments, from chemical and food processing to marine applications. Al Summan Metals employs advanced forging methods and stringent quality control practices to ensure accurate dimensions, uniform mechanical properties, and enduring performance. The company serves industries such as chemical processing, food and beverage, marine, and construction, delivering Stainless Steel 304 forgings that ensure exceptional reliability, efficiency, and operational safety.
**Stainless Steel 304 Forgings** consist primarily of iron, chromium (18–20%), and nickel (8–10.5%), together with small quantities of carbon, manganese, and silicon. This austenitic stainless steel composition delivers outstanding protection against corrosion, oxidation, and scaling. In terms of mechanical properties, Stainless Steel 304 forgings offer notable tensile and yield strength, combined with excellent ductility and toughness. Such qualities make them well-suited for uses that call for durability, dimensional stability, and reliable performance in corrosive and high-temperature environments.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 | – |
| (UNS) | Tensile Strength (MPa) ≥ | Yield Strength ≥ (MPa) at 0.2% Offset | Elongation in 50 mm (%, ≥) | Reduction of Area, %, ≥ | Brinell Hardness (HBW) ≤ | Rockwell Hardness (HRBW) ≤ | Product | Condition |
| 304 (UNS S30400) | 515 | 205 | 40 | – | 201 | 92 | Plate, Sheet, and Strip | – |
| 515 | 205 | 40 | 50 | – | – | Bars and Shapes | Hot finished | |
| 620 | 310 | 30 | 40 | – | – | Cold finished, Dia ≤ 12.7mm | ||
| 515 | 205 | 30 | 40 | – | – | Cold finished, Dia. > 12.7mm |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 304 | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18‐09 | X5CrNi18-10 |
Yes, Stainless Steel 304 forgings can be tailored into a range of shapes using accurate forging methods, providing versatility for various industrial uses and design needs.
To achieve peak malleability and strength when forging Stainless Steel 304, the recommended temperature window falls between 2100°F to 2300°F (1149°C to 1260°C).
You’ll see **Stainless Steel 304 Forgings** commonly employed across industries requiring materials that offer both corrosion resistance and mechanical strength. They frequently appear in valves, flanges, fittings, pump components, and structural parts. Within the chemical, food, and beverage sectors, they function in reactors, piping, and storage tanks that make contact with corrosive substances. Their outstanding mechanical strength, corrosion resistance, and durability likewise make them an ideal choice for marine, pharmaceutical, and high-performance industrial applications. With Stainless Steel 304 forgings, you can rely on lasting reliability, efficiency, and performance, even under the harshest operating conditions.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Summan Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Dubai, UAE
