Al Summan Metals, a well-respected manufacturer and supplier based in Dubai, UAE, is committed to producing high-quality Stainless Steel 304L Forgings. These forgings are renowned for their exceptional corrosion resistance, remarkable strength, and lasting durability, which makes them ideal for demanding industrial applications. Owing to the low carbon content in 304L, they offer excellent weldability and lower the risk of carbide precipitation, ensuring dependable performance even in severe, corrosive environments. Al Summan Metals follows rigorous quality control and precision manufacturing methods, delivering Stainless Steel 304L Forgings that meet international standards for use in the chemical, marine, and food processing industries.
The forgings known as Stainless Steel 304L are composed mainly of iron, 18–20% chromium, and 8–12% nickel, together with small quantities of carbon, manganese, and silicon. Reduced carbon levels improve protection against intergranular corrosion and promote stronger weld quality. Regarding mechanical properties, these forgings provide a tensile strength of about 485 MPa and a yield strength of 170 MPa, demonstrating outstanding ductility and toughness. The steady microstructure ensures longevity, strength, and reliable operation under a range of temperatures and working conditions.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 304L | 1.4306 / 1.4307 | S30403 | SUS 304L | 3304S11 | 03Х18Н11 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 |
Post-forging processes for Stainless Steel 304L involve heat treatment, machining, surface finishing, and testing to guarantee ideal strength, dimensional precision, and corrosion resistance.
To assess whether Stainless Steel 304L forgings are suitable for your requirements, examine material certifications, carry out quality inspections, and confirm they satisfy the necessary mechanical properties and dimensional standards.
Following Stainless Steel 304L forgings, cooling slowly in air or controlled settings is advised to avoid cracking and to guarantee consistent grain structure and mechanical properties.
Stainless Steel 304L Forgings are widely applied in scenarios that call for both resistance to corrosion and mechanical strength. They are especially suitable for parts used in chemical processing equipment, heat exchangers, marine hardware, and food processing machinery. Because their surface is non-reactive and hygienic, they are also perfect for the pharmaceutical and dairy sectors. In addition, 304L Forgings serve in pressure vessels, valves, pumps, and structural assemblies, where toughness and accuracy are vital. Thanks to their adaptability and durability, they remain a preferred option throughout many engineering and industrial domains.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Summan Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Dubai, UAE
