At Al Summan Metals, we are a leading manufacturer and supplier located in Dubai, UAE, dedicated to providing top-quality Stainless Steel 310 Forgings. It is recognized for its outstanding heat resistance and corrosion resistance characteristics, making it well-suited for high-temperature applications that demand strength and dependability. By leveraging advanced technology, we offer customized solutions designed to meet your requirements for excellence. As a well-established company committed to superior craftsmanship and product quality, we can serve as your trusted supplier for premium-quality stainless steel products.
Stainless Steel 310 Forgings consist mainly of iron, combined with elevated levels of chromium (24-26%) and nickel (19-22%), which deliver outstanding oxidation and corrosion resistance. Minor quantities of manganese, silicon and carbon are also present. In terms of mechanical characteristics, they offer high tensile strength, remarkable toughness and exceptional creep strength when exposed to high temperatures. Owing to their resistance to scaling and thermal expansion, these forgings work well in high-temperature settings. Their benefits encompass strong oxidation resistance, outstanding strength under extreme conditions, and lasting durability.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 310 | 0.015 max | 2 max | 0.15 max | 0.020 max | 0.015 max | 24.00 – 26.00 | 0.10 | 19.00 – 21.00 | 54.7 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 310 | 1.4841 | S31000 | SUS 310 | 310S24 | 20Ch25N20S2 | – | X15CrNi25-20 |
Regulating temperature while forging Stainless Steel 310 secures the correct grain structure, boosting its strength and its ability to withstand oxidation. It further reduces the likelihood of defects, guaranteeing uniform quality and performance in high-temperature uses.
Evaluate the forging capability of Stainless Steel 310 for aerospace applications by performing tensile, fatigue, and hardness testing, verifying consistent grain structure and strong high-temperature durability.
Stainless Steel 310 Forgings need little upkeep, generally consisting of routine cleaning to avoid buildup and occasional checks for indications of wear or corrosion, particularly in high-temperature settings.
Stainless Steel 310 Forgings find extensive use in high-temperature settings owing to their outstanding oxidation resistance and thermal stability. They are frequently encountered in sectors like power generation, chemical processing and furnace components. Such forgings work well in heat exchangers, thermal reactors, boiler parts and kiln components. Stainless Steel 310 additionally serves applications where high-strength and scaling resistance are essential, including the manufacturing of gas turbines, refinery equipment and industrial ovens.
We supply materials accompanied by both mill test certificates and third-party test certificates, guaranteeing top-tier quality and compliance.
