Al Summan Metals is a reliable manufacturer and supplier based in Dubai, UAE, with a focus on stainless steel products. Backed by a strong reputation for quality, we provide an extensive selection of materials designed to suit particular requirements. Our Stainless Steel 316L Rectangular Bars are recognised for their outstanding corrosion resistance, strength and durability, which makes them well-suited to a variety of applications that demand dependability and long-lasting performance. At Al Summan Metals, we are dedicated to providing outstanding products and services.
Stainless Steel 316L Forgings are made up mainly of iron, chromium (16-18%), nickel (10-14%), and molybdenum (2-3%), providing outstanding resistance to corrosion and pitting, particularly in chloride settings. Their mechanical properties feature high tensile strength (approximately 520 MPa), along with excellent weldability and toughness. It retains its strength at high temperatures and has a low carbon content, which lowers the chance of carbide precipitation. The benefits include exceptional corrosion resistance, durability, improved toughness, and versatility, which make it perfect for use in demanding environments.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Yes, Stainless Steel 316L is capable of being forged into custom shapes, providing versatility for a range of applications. Its outstanding machinability enables precise fabrication.
Stainless Steel 316L Forgings need little upkeep, mainly routine cleaning to stop corrosion from accumulating. Periodic inspections guarantee lasting performance and durability.
Stainless Steel 316L Forgings can offer reduced strength at extremely high temperatures and tend to cost more than other grades. They may additionally be prone to localized corrosion under certain conditions.
Stainless Steel 316L Forgings are extensively utilized across industries that demand superior corrosion resistance and durability. Typical uses span marine equipment, chemical processing, pharmaceuticals, food processing and power plants. Because they resist chloride environments so well, they are perfectly suited for offshore and coastal structures, along with heat exchangers, pumps, valves and tanks. Moreover, 316L forgings serve in medical devices, aerospace components, and high-temperature settings thanks to their toughness, ease of fabrication, and outstanding mechanical properties.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
