Al Summan Metals is a leading manufacturing and supply chain company based in Dubai, UAE, dedicated to quality steel products for a variety of industries. Backed by years of experience, the company provides a complete lineup of products including Stainless Steel 416 Flat Bars. Recognized for their outstanding durability, corrosion resistance and versatility, these flat pads are perfectly suited for applications that demand high strength and reliability Al Summan Metals is devoted to delivering high-quality products that satisfy customer requirements with precision and performance.
Stainless steel 416 is a martensitic grade that offers strong mechanical properties combined with moderate corrosion resistance. The alloy’s composition includes roughly 12-14% chromium, 0.15% carbon and 0.75-1.50% manganese, plus small amounts of sulfur and phosphorus. This material is recognized for its high durability, which makes it well-suited for complex applications. Its mechanical properties feature a tensile strength of 860 MPa, yield strength of 450 MPa, and hardness ranging from 170 to 220 HB. The corrosion, oxidation and environmental resistance of Stainless Steel 416 are excellent but prone to degradation.
Dimensions: ASTM, ASME
Standard: ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface: hrap, hot rolled pickled or sand blasted finish, cold drawn, polished, hairline
Range: Range – 3.17mm to 350mm dia
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 416 | 0.15 | 14.0 – 12.0 | 1.25 | – | 0.06 | 0.15 | 1 |
| Element | Density, lb/in3 | Melting Point | Electrical Resistivity |
| SS 416 | 0.282 lbs/in3 7 .80 g/cm3 | 2700 – 2790 °F (1488 – 1530 °C) | At 70 °F (21 °C): 343.0 |
| Flat Bar | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.49 | 1.60 |
| 18 | 0.62 | 2.02 |
| 20 | 0.76 | 2.49 |
| 22 | 0.92 | 3.02 |
| 25 | 1.19 | 3.90 |
| 28 | 1.49 | 4.89 |
| 28 | 1.49 | 4.89 |
| 30 | 1.71 | 5.61 |
| 32 | 1.95 | 6.38 |
| 36 | 2.46 | 8.08 |
| 38 | 2.74 | 9.00 |
| 40 | 3.04 | 9.97 |
| 45 | 3.85 | 12.62 |
| 50 | 4.75 | 12.62 |
| 56 | 8.96 | 19.55 |
| 60 | 6.84 | 22.44 |
| 65 | 8.03 | 26.34 |
| 70 | 9.31 | 30.54 |
| 75 | 10.69 | 35.06 |
| 80 | 12.16 | 39.89 |
| 90 | 15.39 | 50.49 |
| 100 | 19 | 62.34 |
Stainless Steel 416 Flat Bar is typically employed in applications that call for moderate corrosion resistance, high strength, and machinability. It serves in shafts, valves, pumps, fasteners, and machinery components, especially within the automotive, aerospace, and manufacturing industries.
The hardness of Stainless Steel 416 Flat Bar generally falls between 30 and 40 HRC (Rockwell Hardness Scale). This level can differ based on the heat treatment method applied, with greater hardness obtained through quenching and tempering.
Turning, milling, drilling, and grinding are among the typical techniques used to machine Stainless Steel 416 Flat Bar. Thanks to its excellent machinability, it can be worked with standard tools without difficulty, although cutting speeds and coolant application should be fine-tuned to minimize heat accumulation.
Stainless Steel 416 Flat Baris used in situations demanding high machinability, moderate corrosion resistance, and strength. It is primarily used to produce components like shafts, valves, gears, and fasteners. It is highly suitable for the aerospace, automotive, and machinery industries. This alloy offers good machinability; therefore it can be machined with ease and used for precision parts and high-tolerance applications. In addition, it serves the chemical processing and marine industries owing to its mild corrosion resistance – this keeps it durable in moisture and chemical settings that involve moderate exposure.
We supply products accompanied by mill test certificates as well as third-party test certificates, guaranteeing the highest levels of quality and compliance.
