Al Summan Metals, based in Dubai, UAE, is a well-regarded manufacturer and supplier focused on precision-engineered Titanium Grade 1 Forgings. Known for their commitment to quality and reliability, Al Summan Metals offers premium titanium products that perform outstandingly in critical applications. Through the use of advanced forging technology and stringent quality control practices, the company ensures remarkable dimensional accuracy, purity, and mechanical consistency. With a strong focus on innovation and customer satisfaction, Al Summan Metals supplies Titanium Grade 1 forgings that meet international standards, serving clients in aerospace, chemical processing, marine, and medical industries with materials that provide strength, corrosion resistance, and lightweight characteristics.
Al Summan Metals produces Titanium Grade 1 Forgings using commercially pure titanium (Ti ≥ 99.5%), containing minimal amounts of iron (≤0.20%), oxygen (≤0.18%), nitrogen (≤0.03%), carbon (≤0.08%), and hydrogen (≤0.015%). This precise makeup ensures outstanding corrosion resistance and superb formability. When it comes to mechanical properties, Grade 1 titanium delivers a tensile strength of roughly 240 MPa, a yield strength near 170 MPa, and elongation reaching up to 24%. Featuring notable impact toughness and remarkable ductility, it’s ideal for uses that demand top-tier weldability, a low density of 4.51 g/cm³, and outstanding resistance to seawater and oxidizing conditions.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | O | N | Fe | H | Ti | I |
| Min | – | – | – | – | – | 99.095 | – |
| max | 0.080 | 0.18 | 0.030 | 0.2 | 0.015 | 100 | 0.2 |
| Grades | Tensile KSI Min | Yield KSI Min/Max | % Elongation Min |
| Titanium Gr 1 | 35 | 25/45 | 24 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Grade 1 | 3.7025 | R50250 |
Titanium Grade 1 forgings are widely applied across the aerospace, chemical processing, marine, medical, and automotive sectors thanks to their outstanding corrosion resistance, low weight, high strength, and biocompatibility characteristics.
Titanium Grade 1 forgings are produced by heating titanium billets and then forming them through compressive forces such as hammering or pressing, after which precision machining is carried out to reach the required specifications.
Open-die forging for Titanium Gr 1 works by pressing heated titanium between flat or shaped dies, letting the metal flow freely, which yields strong, tailored parts with outstanding structural integrity.
Al Summan Metals’ Titanium Grade 1 Forgings are widely applied across numerous industries that demand both lightweight strength and resistance to corrosion. Within the chemical processing sector, they serve in heat exchangers, reaction vessels, and piping systems. In aerospace, these forgings play a vital role in airframe components and hydraulic fittings, where cutting weight and boosting performance are essential. In marine environments, they resist saltwater corrosion, making them well-suited for propeller shafts and marine fasteners. Furthermore, they are employed in medical applications, highlighting their adaptability and dependability.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
