Al Summan Metals distinguishes itself as a premier manufacturer and supplier of premium Titanium Grade 3 Bars and Rods, proudly located in Dubai, UAE. Recognized for our precision engineering and dedication to exceptional material standards, we guarantee that our products satisfy both national and international specifications. Our Titanium Grade 3 Bars and Rods achieve the ideal harmony among strength, ductility, and corrosion resistance, positioning them as a preferred option for challenging industrial applications. With a firm emphasis on quality assurance, prompt delivery, and customer satisfaction, Al Summan Metals is committed to serving numerous sectors, such as aerospace, chemical processing, marine, and medical industries, with dependable and high-performance titanium products.
Titanium Grade 3 consists mainly of titanium (≥99.2%), together with small quantities of iron (≤0.30%), oxygen (≤0.35%), carbon (≤0.08%), nitrogen (≤0.05%), and hydrogen (≤0.015%). It offers outstanding resistance to corrosion and moderate strength among the commercially pure titanium grades. In terms of mechanical characteristics, it has a tensile strength of roughly 450 MPa, a yield strength of approximately 380 MPa, an elongation of 25%, and a density of 4.51 g/cm³. Because of its good formability, weldability, and biocompatibility, it makes an excellent option for demanding engineering and medical uses.
| Standards : | ASTM B348, B863 / ASME SB348, SB863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr 3 | 3.7055 | R50550 |
| Grade | C | N | O | H | Ti | Fe |
| Titanium Grade 3 | 0..08 max | 0.05 max | 0.35 max | 0.015 max | Bal | 0.30 max |
| Tensile Strength | Reduction of area | Elongation | Hardness |
| 450 | 30 | 18 % | 90 |
| Density | 0.163 lbs/in³ ,(4.51 g/cm³) |
| Mean Coefficient of Thermal Expansion | in/in/°F (mm/m/°C): 70- 212°F (20- 100°C) 4.78 x 10-6(8.6) |
| Thermal Conductivity | BTU-in/h-ft-°F (W/m-°K): At 70°F (21°C): 138 (19.9) |
| Modulus of Elasticity, ksi (MPa) | 15.2 x 10³ (105 x 10³) in tension |
| Melting Point | 3020°F (1660°C) |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Titanium Grade 3 Round Bars Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Yes, Titanium Grade 3 offers outstanding corrosion resistance in harsh conditions such as seawater, chemicals, and high-temperature environments, which makes it well-suited for the marine and chemical processing industries.
Yes, Titanium Grade 3 offers good weldability, which makes it well-suited for a range of applications that call for welding.
Yes, we supply bars and rods in both standard and custom sizes and finishes to suit your particular project needs. For further information, email us at sales@alsummanmetals.ae
Titanium Grade 3 Bars and Rods are employed across numerous industries where high strength and corrosion resistance are essential. In aerospace, they serve in airframe components and hydraulic systems. The chemical and marine sectors depend on them for heat exchangers, condensers, and seawater piping, owing to their resistance to oxidizing and mildly reducing environments. In the medical field, they’re vital for surgical instruments and orthopedic implants because of their biocompatibility. Additionally, they’re also applied in power generation, desalination plants, and industrial equipment where durability, lightweight design, and outstanding corrosion resistance are essential.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
