Al Summan Metals, a highly regarded manufacturer and supplier based in Dubai, UAE, is committed to providing premium-quality **Titanium Grade 7 Bars and Rods** designed to satisfy diverse industrial requirements. Celebrated for their outstanding corrosion resistance and superior strength, these bars are manufactured through advanced technology and stringent quality control measures. Titanium Grade 7, alloyed with palladium, delivers excellent resistance to reducing acids and chloride-containing environments. Al Summan Metals caters to numerous sectors, such as chemical processing, marine engineering, and aerospace, offering precision-engineered products that comply with international standards, guaranteeing exceptional performance, durability, and dependability even under the most demanding conditions.
**Titanium Grade 7 Bars/Rods** consist chiefly of titanium (≥ 99%), along with a modest amount of palladium (0.12–0.25%) that enhances their resistance to corrosion. They additionally include trace quantities of elements such as oxygen, nitrogen, carbon, hydrogen, and iron. These bars deliver outstanding mechanical properties, with a tensile strength of roughly 345 MPa, a yield strength near 275 MPa, and 20% elongation. They are recognized for their exceptional toughness, excellent formability, and remarkable weldability. Because they combine lightweight strength with corrosion resistance, Titanium Grade 7 is ideal for demanding chemical and marine settings.
| Grade | ASTM B348 Ti Gr7 Flat Bar |
|---|---|
| Titanium Grade 7 Square bar size | 4 to 100mm |
| Titanium Alloy Grade 7 Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| CP Titanium Alloy Gr7 Hex Bar size | 2-100mm A/F |
| Titanium Grade 7 Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Titanium Alloy Grade 7 Rectangles Size | 33 x 30mm to 295 x 1066mm |
| CP Titanium Alloy Gr7 Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Titanium Grade 7 Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Titanium Alloy Grade 7 Section | 3.0 to 12.0mm thickness |
| CP Titanium Alloy Gr7 Round bar size | Diameter: 3-~800mm |
| Titanium Grade 7 Billet Size | 1/2″ to 495mm Diameter |
| Titanium Alloy Grade 7 Round Bar Standard Dimensions | Diameter / Height: |
| Titanium Grade 7 Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Titanium Alloy Grade 7 Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| CP Titanium Alloy Gr7 Technique | Titanium Grade 7 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Titanium Grade 7 Condition | Hardened & tempered, annealed |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Form | Titanium Grade 7 Round, Rod, T-Bar, Nickel Alloy Channel Bar, Precision Ground Bar, Nickel Alloy Flat Bar, Nickel Alloy Square Bar, Nickel Alloy Blocks, Nickel Alloy Round Rod, Nickel Alloy Rings, Nickel Alloy Hollow, Nickel Alloy Triangle, Rectangle, Hex (A/F), Nickel Alloy Threaded, Half Round Bar, Profiles, Nickel Alloy Billet, Nickel Alloy Ingot, I/H Bar, Forging etc. |
| Processing | Bar cutting to 650mm |
| Our Titanium Grade 7 Round bar conforms to NACE MR0175/ISO 15156 | |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 7 | 3.7235 | R52400 |
| Grade | C | Fe | N | Ti | H | O | Pd |
| Titanium Gr. 7 | 0.08 max | 0.30 max | 0.03 max | Balancen | 0.0150 max | 0.25 max | 0.20 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.163 lb/in3 | 1668 °C | Psi – 39900 , MPa – 275 | Psi – 59500 , MPa – 410 | 20 % |
| Density | Melting Range | Modulus of Elasticity (Tension) | Specific Heat | Mean Coefficient of Expansion | Thermal conductivity | Electrical Resistivity |
| kg/m3 | °C | GPa | J/kg. °C | x10 -6 / °C | W / m. °C | micro-ohm.m |
| 4,507 | 1668± 10 | 103 | 519 | 8.41 | 11.4 | 0.420 |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Titanium Grade 7 Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Titanium Grade 7 Bars and Rods are indeed recyclable. Titanium can be recycled to a high degree without notable loss of its properties, which makes it an environmentally sustainable material that can be reused across a range of applications.
Yes, we supply bars and rods in both standard and custom sizes and finishes to suit your particular project needs. For further information, email us at sales@alsummanmetals.ae
No, Titanium Grade 7 Bars and Rods are not drawn to magnets. Titanium, Grade 7 included, is a non-ferromagnetic material, which means it possesses little to no magnetic characteristics and is not pulled toward magnets.
**Titanium Grade 7 Bars and Rods** see widespread use across industries that require both strong corrosion resistance and mechanical strength. They are especially well-suited to chemical processing equipment, heat exchangers, condensers, and piping systems exposed to oxidizing as well as reducing acids. Within the marine sector, they serve in desalination plants, offshore structures, and seawater handling systems. The aerospace and power generation fields rely on them for components that call for materials that are both lightweight and durable. Beyond that, they appear in medical implants, electroplating systems, and pollution control equipment. Thanks to their outstanding weldability and mechanical stability, they remain a preferred option across a range of applications.
We provide items that are supplied with mill test certificates as well as third-party test certificates, guaranteeing the highest levels of quality and compliance.
