Al Summan Metals, a well-respected manufacturer and supplier located in Dubai, UAE, has built a solid reputation for supplying premium steel products, such as 1141 Cold Drawn Bars and Rods. Owing to its commitment to precision engineering, cutting-edge manufacturing technology, and rigorous quality control, Al Summan Metals guarantees that each product meets international standards for performance and durability. The company caters to a broad spectrum of industries, such as automotive, machinery, and construction. Recognized for its dependability, consistency, and technical know-how, Al Summan Metals continues to provide 1141 Cold Drawn Bars and Rods that deliver exceptional strength, machinability, and surface finish, making them well-suited for demanding industrial applications.
The 1141 Cold Drawn Bars and Rods are manufactured from medium carbon manganese steel, holding approximately 0.37–0.45% carbon, 1.35–1.65% manganese, along with small quantities of phosphorus and sulfur to improve machinability. The cold drawing process enhances both dimensional precision and surface finish while boosting strength. These bars typically exhibit tensile strengths between 655 and 825 MPa, coupled with good hardness and machinability. 1141 steel delivers an outstanding balance of strength and ductility, making it an excellent choice for applications demanding precision, fatigue resistance, and moderate wear resistance under mechanical stress.
|
Category |
Steel |
|
Class |
Carbon steel |
|
Type |
Standard resulfurized |
|
Designations |
United States: ASTM A107 , ASTM A108 , ASTM A29 , ASTM A311 , FED QQ-S-637 , SAE J403 , SAE J412 , SAE J414 , UNS G11410 |
|
Carbon |
.37 |
|
Manganese |
1.35-1.65 |
|
Phosphorus (max) |
.04 |
|
Sulfur (max) |
.08-.13 |
|
Tensile strength |
97 ksi |
|
Yield strength |
52 ksi |
|
Elongation in 2” |
22% |
|
Reduction of Area |
38% |
|
Brinell Hardness |
The available thicknesses for 1141 Cold Drawn Bar typically span 1/4 inch to 2 inches in diameter or cross-section, depending on supplier specifications and manufacturing standards.
Carbon Steel 1141 Bars are employed in applications requiring high strength, wear resistance, and machinability, including automotive parts, gears, shafts, fasteners, and industrial machinery components. Ideally suited for medium-duty applications.
Carbon Steel 1141 rods deliver high tensile strength (~725 MPa), solid yield strength (~415 MPa), moderate hardness (~197 HB), outstanding machinability, and restricted weldability, which makes them a good fit for wear-resistant applications.
1141 Cold Drawn Bars and Rods are widely employed in applications that call for high strength, solid machinability, and exceptional dimensional accuracy. They work perfectly for making shafts, bolts, studs, pins, spindles, gears, and fasteners in the automotive and machinery industries. Thanks to their enhanced surface finish and mechanical strength, they also suit precision-engineered parts and components exposed to moderate stress. In construction and equipment manufacturing, these bars fulfill both structural and mechanical roles. Al Summan Metals’ 1141 Cold Drawn Bars and Rods provide reliability, efficiency, and durability across a wide range of industrial and engineering applications.
We supply products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
